Specifications
Auto tool changer with four Axis CNC Router1. working area:1300*2500mm
2. Italy HSD 9kw air cooling
3. Servo motor
4. Synt
Auto tool changer with four Axis CNC Router
Applicable industry and material:
1. The mold industry: casting, automotive, wind power, ships, boats, aerospace industry, rail transport.
2. The instrument industry: three-dimensional surface of large musical instruments, cutting and shaping.
3. Applicable materials: polystyrene foam (EPS), and wood, timber and non-metallic carbon hybrid materials
Features:
1. The spindle can rotate 180 degree, can make multi-kinds of surface which we can design with Software.
2. We use We use top quality components for the machines, like HSD spindle, Syntech EZ-4M control system, Delta Inverter (or Fuling Inverter for 240V), Yaskawa servo motors, and separate control box, Hiwin linear and so on, to keep the machine in the best condition even after many years working.
3. The machines’ body is strong, rigid, high precision, reliable and durable.
4. Imported high-precision ball screw gap, smooth movement, to ensure that the machine tools high-precision..
5. Using well-known domestic brands of water-cooled brushless spindle, low noise, strong cutting ability, to ensure the long time working.
6. High-performance driven motor to ensure that the machines high speed and accuracy
7. Designer perfectly, select the best machine accessories , to minimize the failure rate preferred
8. Breakpoint specific memory, power outages continued carving, processing time forecast, and other functions to ensure that accidental processing
|
Description |
Parameter |
1 |
X,Y,Z Working Area |
1300x2500x400mm*180degree |
2 |
Table Size |
1450×2940mm |
3 |
X,Y,Z Traveling Positioning Accuracy |
±0.03/300mm |
4 |
X,Y,Z Repositioning Accuracy: |
±0.03mm |
5 |
Table Surface |
Vacuum and T-slot Combined (Option: T-slot Table) |
6 |
Frame |
Big Steel Tube Structure |
7 |
X, Y Structure |
Rack and Pinion Drive, Hiwin Rail Linear Bearings |
8 |
Z Structure |
Hiwin Rail Linear Bearings and Ball Screw |
9 |
Max. Power Consumption |
(Without Spindle) 4.5Kw |
10 |
Max. Rapid Travel Rate |
40000mm/min |
11 |
Max. Working Speed |
30000mm/min |
12 |
Spindle Power |
Italy HSD 3KW Air-cooling Spindle |
13 |
Spindle Speed |
0-24000RPM |
14 |
Drive Motors |
850W Yaskawa Motors |
15 |
Working Voltage |
AC380V/50/60Hz,3PH (Or 220V±30V/50/60Hz) |
16 |
Command Language |
G Code |
17 |
Operating System |
Syntec Control System |
18 |
Computer Interface |
Ethernet |
19 |
Flash Memory |
512M |
20 |
Collet |
ER32 |
21 |
X,Y Resolution |
<0.03mm |
22 |
Software Compatibility |
Type3/UcancameV9 software (Option: Artcam software) |
23 |
Running Environment Temperature |
0 - 45 Centigrade |
24 |
Relative Humidity |
30% - 75% |
25 |
Packing Size |
3300X2100X2300mm |
26 |
N.W. |
1750KG |
27 |
G.W. |
2150KG |
|
Optional |
Rotary System |
Mist-cooling System | ||
Delta/ Panasonic Servo Motors | ||
Colombo Spindle |
