Help CenterRecycled Plastics Granules
Related Products
Supply Recycled plastics granules
1. Technical specifications of plastic recycling machine
+PET Bottle Recycling Machine
+Mass production,short delivery time
+CE,ISO,SGS
+Auto operation
+High effiency
2. What we can do of Recycled plastics granules ?
3. Recycled plastics granules and advantage:
This Recycled plastics granules is a ideal PET washing line.
This unit is mainly for Recycled folding waste plastics and pelletizig line : the labels and bottle caps are automatically separated, then after being washed, dewatered and dried, the water content will be very low, and PP/PE film after being washed can be directly granulated (water-ring palletizing), the gained granules are even and smooth with shiny surface. So, it is an ideal equipment in waste plastic recycling industry, with leading technology in the world.
We professionally manufacture plastic machinery and waste plastic washing production lines, such as PET (bottle) flakes washing lines, PP/PE waste plastic film washing and granulating/palletizing production lines, pipes and shape pipes production lines, and various auxiliary machines.
Our products are more reasonable in design, more excellent in processing and more durable in usage.
To separate Recycled folding waste plastics and pelletizig line , cap, oil, garbage, protect the environment, avoid white pollution.
This recycling line is composed of separator, crusher, cold & hot washing system, dewatering, drying, packing system, etc.
This Recycled plastics granules can easily wash and recycle waste PET bottle flakes. Waste and dirty PET bottle flakes can be treated step by step by this facility. It is special for washing PET bottles flakes. We can help to attach equipment at the end of the washing line so that the completely dry flakes can be collected and packed directly after being washed. The whole production line can be designed on the basis of how dirty the flakes are, and make sure of the quality of the final products. Coordinating the production line with follow programmed work (granulating system), and it will make waste and dirty PET bottles to be the PET granule material and in order to producing new PET bottles. After the this PET bottle flakes crushing, recycling and washing production line, our company also offer the following production lines of PET bottle granulating to make the waste and dirty PET bottle be the new finished products.
4. With using our machine what you will get?
5. Which parts combined to our machine?
NO |
ITEM |
DESCRIPTION |
SELECTIVITY |
1 |
Pre-washer |
Remove the solid impurity which are water insoluble, such as hand stone, sand, etc. It can also wash bottles' surface. |
Optional |
2 |
Bale Breaker |
It is used in large capacity recycling line, and bottles are compressed in bale. |
Optional |
3 |
Belt Conveyor |
Including the metal detector. |
Necessary |
4 |
Label Remover |
Label removing efficiency, more than 98% |
Optional |
5 |
Manual Select Platform |
Made according to workers' height, supply a suitable plate for selecting the left labels or some other impurity. |
Optional |
6 |
Belt Conveyor |
Conveying the bottles into crusher. |
Necessary |
7 |
Crusher |
With water, the materials of the blade adopt SKD-II or 9CrSi. It has a function of prewashing too. |
Necessary |
8 |
Screw Feeder |
Conveying the flakes into friction washer. |
Optional |
9 |
Friction Washer |
Scrubbing material in high-speed with water. |
Optional |
10 |
Screw Floating Washer |
Remove few remand paper, sand, label from material based on different density. |
Optional |
11 |
Screw Feeder |
Conveying the flakes into hot washer. |
Necessary |
12 |
Hot Washer |
High temperature stirring washing with caustic soda. Water can be heated by steam or electric. |
Necessary |
13 |
Screw Feeder |
Same as Item 8. |
Necessary |
14 |
Friction Washer |
Same as Item 9. |
Necessary |
15 |
Screw Floating Washer |
Same as Item 10. |
Necessary |
16 |
Dewatering Machine |
High speed centrifuge drying. |
Necessary |
17 |
Drying System |
Electric heating wind drying. |
Necessary |
18 |
Label Wind Separator |
The last left impurity will be separated from flakes by the blower fan. |
Optional |
19 |
Silo |
Store the final material. |
Necessary |
20 |
Electrical Control Panel |
Adopts Siemens and DELIXI as main component. |
Necessary |
6. Our machines show:
7. Our valued customers:
8. Loading show:
For more information please visiting us @
