ITC T-60 (Phone Jack MIC Input) 60w Power Mixer Amplifier

US$ 37 - 425 MOQ: 10 Units

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

ITC

Model Number:

T-60 Power Mixer Amplifier

Guangzhou Baolun Electronics Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Guangzhou Shenzhen or HK

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name ITC

Model Number T-60 Power Mixer Amplifier

ITC T-60

(Phone Jack MIC Input) 60w Power Mixer Amplifier

Features

* Mixer amplifier for paging and background music system

* Rated power from 60W, 120W, 240W, 350W, 500W to 650W

* 2U rack mount (less than 350W) and 3U rack mount design

* 70V, 100V and low impedance 4-16ohm speaker output

* Three Mic inputs by phone jack type

* Mic 1 with VOX priority and VOX level on front panel

* Mic 2-3 by phone jack on rear panel

* Two Aux Inputs and 2 line inputs for spare use

* One EMC priority input

* EMC has priority over all inputs except MIC1

* Mic 1-3, Aux 1-2 and master volume controls and bass/treble tone control

* Short circuit, overload and high temp protection

Specification

Model	T-60	T-120		T-240
Rated Power Output	60W	120W		240W
Speaker Outputs	70V, 100V & 4~16Ω
Input Sensitivity & Impedance	MIC 1, 2, 3: 5mV/600Ω , Unbalanced phone jack input MIC 2, 3: 775mV/10KΩ, Unbalanced RCA input AUX 1, 2: 350mV/10KΩ , Unbalanced RCA input EMC: 775mV/10KΩ , Unbalanced RCA input
Output Sensitivity & Impedance	MIX OUT: 1V/470Ω , Unbalanced RCA output
Tone	Bass: ±10dB at 100Hz Treble: ±10dB at 10KHz
Frequency Response	50Hz~16KHz(+1dB, -3dB)
S/N Ratio	MIC 1, 2, 3: 66dB, AUX 1, 2: 80dB
THD	Less than 0.5% at 1KHz, 1/3 rated power
Muting Function	MIC 1 overrides other input signals with 0-30dB attenuation
Crosstalk	≤50dB
Cooling	Fan automatically start up when temp reaches 55°C
Protection	High temp, overload & short-circuit
Power Supply	~110V/60Hz or ~230V/50Hz or DC 24V
Power Consumption	100W		200W		400W
Weight	7.1Kg		9.3Kg		16.6Kg
Dimensions	484 x 335x88mm				484x 385x88mm
Finish	Panel: aluminum plate, black Case: steel plate, black
