<MUST Solar>Power Guard UPS Inverter LCD Display 600W 1200W

Shenzhen Must Solar Power Co., Ltd.
<MUST Solar>Power Guard UPS Inverter LCD Display 600W 1200W thumbnail-1
<MUST Solar>Power Guard UPS Inverter LCD Display 600W 1200W photo-1
US$ 51 - 65 MOQ: 6 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
MUST Solar
Model Number:
PG Series dc ac power home ups, PG Series home inverter
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen/HongKong
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name MUST Solar
Model Number PG Series dc ac power home ups, PG Series home inverter
Output Power 1 - 200KW
Output Type Other, Single, Single
Size 224*255*80mm
Weight 3kgs
Input Voltage 110v/120v/220v/230v, 110v/120v/220v/230v
Output Voltage 110v/120v/220v/230v
Type DC/AC Inverters
Output Frequency 50Hz/60Hz, 50Hz/60Hz
Output Current 10A/20A

Specifications

*high frequency transformer
*double PCB boards
*20A/10Amp battery charger
*LCD display(new mould)
*OEM service

<MUST Solar>Power guard UPS inverter LCD display 600W 1200W







NEW FUNCTION 10A/20A CHARGING CURRENT ADJUSTABLE



<MUST Solar>Power guard UPS inverter LCD display 600W 1200W







PG Series Home Inverter NEW Panel:

<MUST Solar>Power guard UPS inverter LCD display 600W 1200W



PG Series 1KVA 2kVA 10A/20A Battery Charging Current  DC to AC Mini Home Inverter







10A/20A Charging Current 1000VA 2000VA DC to AC Home Power Inverter

PG modified sine wave inverter is a combination of an inverter and a charge. It offers a smart, convenient and economic way to get AC power supply from DC source for most electrical equipment. When the AC input is available, it will switch to AC power supply and starts charging on the batteries.

The PG series converts DC power into AC power. With a continuous output and compact design, the units is ideal for running TVs, Stereos, Laptop and computers and other home appliances .PG series will automatically transfer to inverter and provide power when AC supply is interrupted unexpectedly.




Home Power Inverter Features:Wide Input range 90-280VAC





Home Power Main Feature:



1.Automatic line-to-battery switchover
2.selectable input voltage ranges, power inverter has wide input range:90-280Vac



narrow input range:170-280Vac
3.small power inverter has high efficient DC-to-AC conversion, minimizing energy loss



4.Rack Tower design for flexible placement
5.small power inverter built-in enhanced charger 8Amps for up to 100Ah battery
6.Intelligent 2-stage charger control for efficient charging and preventing overcharge
7.overload protection
8.auto restart while AC recovery
9.Multi-function LED indications and buzzer alarms



10.small scale and cost effective inverter for home appliance and office equipment



11.LED indicator of power inverter for the battery mode, AC mode, battery charging mode, overload mode and fault warning



12. over 95% efficiency in AC to AC mode



13. audible alarm for the low battery, overload, overcharge and fault



14. full protection of power inverter against deep discharge, overcharge, overload protection, short circuit, overvoltage and under voltage (compact power inverter)





Home Power Inverter Applications:
Main for home and office Appliance such ad computer, TV, lights, fan etc.





1.Home Power Inverter Specifications:



PG Series Power Inverter 500va /1000va /2000VA  LCD Display


Rated Capacity 500VA/300W1000VA/600W2000VA/1200W

1.Input

Models 120V Models230V Models
Nominal Voltage 110V/115V/120V Selectable220V/230V/240V Selectable
Input Frequency 47Hz ~ 65Hz,  50/60Hz Auto-Sensing
Efficiency 95%(Normal Mode)
Noise Filtering Full Time EMI/RFI Filtering
Over Current Protection By Re-Settable Over Current Protector
Voltage Range 90 - 145VAC Or 170-280VAC ( Narrow Range ) 50-145VAC / 90 280VAC (Wide Range)
Surge Protection 324 Joules

2.Output

Rated Power500va/300w1000VA/600W2000VA/12000W
Output Voltage 100V/110V/115V/120V Selectable200V/220V/230V/240v selectable
Voltage Waveform Modified Sine Wave
Crest Factor 3:1
Output Frequency
(Synchronized To Mains) 		Auto Select For 50/60Hz
47Hz ~ 55Hz For 50Hz Nominal
56Hz ~ 65Hz For 60Hz Nominal
Regulation (Battery Mode) 10% -18%
Transfer Time 15ms Typical 50ms Max
Protection Over Load, Discharge, Overcharged



Battery Type Lead-Acid 12V 25Ah  ~ 250Ah
Voltage 500VA/1000VA :DC12V ; 2000VA :DC24V
Backup Time Depend On Battery
Charging Method 3 Steps Super Charge Mode
Charging Current 10A At Normal Line And Normal Temperature
Protection Over Current Protection Over Charging Voltage Protection  (No More Than 15V) Deep Discharge,  Overload Protection

3.Communications & Management

Control Panel (LED Indicator ) Ac ModeGreen Lighting
Battery ModelYellow Lighting
Battery Charging  ModeGreen Flashing Every 2 Seconds
Over LoadRed Flashing Every 0.5 Second
FaultRed Lighting
Audible Alarm Low BatterySounding Every 2 Seconds
OverloadSounding Every 0.5 Second
FaultContinuously Sounding

4.Environment And Safety

Operating Environment 0~40 Degrees Centigrade, 0 - 90% Non Condensing
Transit/Storage Temperature -15°C To 55°C (5°F To 131°F)
Operating Altitude 0 ~ 3000 Meters
Audible Noise 50dba
Safety Markings CE.FCC
Quality Control System ISO 9001

5.Physical

Dimensions(H×D×W) 355*130*230mm
N.W / G.W(Kg) 1.6  / 2 (Kg) 2 / 2.3 (Kg)2.2 / 2.6 (Kg)
Packing 6pcs/Carton




2.PG Home Power inverter Data Sheet:



NEW:



<MUST Solar>Power guard UPS inverter LCD display 600W 1200W





DC to AC Home Power Inverter LCD display:









 3.Home Power Inverter PG Series Inside:







4.Home power inverter PG Series 1000VA-2000VA Packing:





Home Power Inverter With Battery Cable:











<MUST Solar>Power guard UPS inverter LCD display 600W 1200W





PG Home power Inverter Socket And Cable:











5.Home Power Inverter Production Line:







Home Power Inverter Test Machine:







HongKong Electronice Fair:



<MUST Solar>Power guard UPS inverter LCD display 600W 1200W



  PG Series 1KVA 2kVA 10A/20A Battery Charging Current  DC to AC Mini Home Inverter
