T-6705B
Digital IP Digital Amplifier IP Network adapter For IP Audio System
The T-6705B is a wall mount network audio adapter built-in amplifier for network audio system, its distinctive features is built-in speaker line backup. One line is built-in low impedance speaker line, once this line is failure to receive network source, it will automatically switch into the backup 100V PA system to ensure the local sound system is working continuously without any interference.
It is a best seller model for IP/TCP network audio system solution. It is used to transmit program from internet to its built-in amplifier then to low impedance loudspeakers. So the normal connection way as below: Control port by RJ45 connector to LAN switch and speaker outputs to loudspeakers.
The IP network audio adapter is of wall mount design, it is built-in a 10W digital Class-D amplifier, so it is usually installed in the terminal room together with a pair low impedance speakers for a small sized application.This LAN network technology also allow this IP network audio adapter with amplifier could be installed anywhere of the LAN system, thus the cable wiring cost could be saved.
The biggest advantages of the network audio system are: Super distance audio transmission, simultaneousmaximum program task and non-dedicated network wiring. A 4 ohms loudspeaker could be directly powered by the built-in 10W power amplifier.
Model |
T-6705B |
Network Input |
Standard RJ45x3, 1 Input, 2 Output |
Protocol Support |
TCP/IP, UDP, IGMP (group broadcasting) |
Audio Formats |
MP3/MP2 |
Sampling Rate |
8K~48KHz |
Transmit Speed |
10Mbps |
Audio Format |
16 digit stereo CD tone |
Frequency Output |
20Hz~16KHz |
THD |
≤0.3% |
S/N |
≥70dB |
|
Speaker Output Impedance And Rated Power Output |
4 ohm, 10W Industrial Standard Screw terminals |
Aux Line Voltage Input |
2x400mV Industrial Standard Screw terminals |
Sources Voltage Output |
2x775mV Industrial Standard Screw terminals |
Mandatory Input |
0V Industrial standard screw terminals |
Source Impedance Output |
1 |
MIC Input S/N |
10mV |
Working Temperature |
5 ℃~40℃ |
Working Humidity |
10%~90% |
Power Consumption |
≤40W |
Power Supply |
~110V/60Hz or ~230V/50Hz |
Dimensions |
359x245x65mm |
Weight |
4.20Kg |
