VA-6000FM
China Digital professional wireless fire alarm system manufacturer
VA-6000FM could control emergency voice alarm system remotely. It allows users to select the voice message and do zoning paging. It supports 8 zones/groups and it could be expanded via expansion unit. It could do cascade with up to 7 expansion units and each unit support 8 zones so that the Max. Quantity of zone is 64.
Easy operation.
It’s connected to the host via CAT5 so that the transmission distance is much longer.
Complete indication to display the system fault and the status of main modules.
Support zone expansion.
With line input and it has volume control.
Support spare line.
Could be powered up by phantom power at 24V.
Function:
Mic output is with volume control.
Its priority could be adjusted by the matching software VA-6000ST.
Built in Hifi speaker to do monitoring.
A hot key to trigger emergency PA status
With earphone jack to do monitoring and recording.
DC Supply | |
Power Supply |
24V DC, ±20% |
Maximum Current |
0.1 A(including extension unit) |
Power Comsumption |
2.4W(including extension unit) |
Perfermance | |
Parallel Signal Output | |
THD |
<1%(rated output power),1kHz |
Frequency |
80Hz~16kHz |
Sensitivity |
500mV |
Impedance |
10kΩ |
S/N Ratio |
>70dB |
Line In | |
THD |
<1%(rated output power),1kHz |
Frequency |
80Hz~16kHz |
Sensitivity |
350mV |
Impedance |
10kΩ |
S/N Ratio |
>70dB |
Microphone | |
Sensitivity |
5mV |
Impedance |
600Ω |
Machine | |
Demension( L×W×D ) |
256×52×149mm |
Net Weight |
1.5kg |
Mounting |
Desktop or 18 inch cabinet |
Color |
Black |
Environment | |
Operation Temperature |
+5℃ ~ +40℃ |
Storage Temperature |
-20℃ ~ +70℃ |
Relative temperature |
<95%(no condensation) |
ITC promise the electronics yearly failure rate is less than 1%.
ITC guarantee all electronics of 3 years quality warranty.
ITC could supply 1% wearing spare parts free of charge.
ITC guarantee all loudspeakers of 6 months quality warranty.
All of quality complaint shall be attached with serial number, failure test report and photos.
All of the quality compliant shall be feedback with a solution within 48 hours.
ITC could supply circuit diagram documents for repair.
Full-sealing package of Products:
We adopt full-sealing bubble film+strech film+wood frame (or wood box). It will keep the moist from entering into the package to make the products rusted.
