Home > Consumer Electronics > Audio & Sets > Professional Audio > Professional 72x72 Multimedia Matrix Control System Matrix Switcher

Professional 72x72 Multimedia Matrix Control System Matrix Switcher

Professional 72x72 Multimedia Matrix Control System Matrix Switcher photo-1

Professional 72x72 Multimedia Matrix Control System Matrix Switcher photo-2

US$ 26,000 - 58,230 MOQ: 1 Set

Key Specifications

Get Latest Price

Place of Origin:

Guangdong, China

Brand Name:

ITC

Model Number:

TS-9272H

Contact Supplier Request Quote Chat Now

Guangzhou Baolun Electronics Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Guangzhou Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Guangdong, China

Brand Name ITC

Model Number TS-9272H

Professional 72x72 multimedia matrix control system matrix switcher

Product Description

Matrix switcher is a matrix signal switcher with flexible configuration.

It adopts high-performance hardware design, perfectly supports all kinds of high-definition digital/analog signal switch processing, and supports bi-directional RS-232 and bi-directional IR signal switching function.

Providing a one-stop solution for a variety of video and control signal distribution switching processes, it can be widely used in radio and television engineering, multimedia conference room, large screen display engineering, television education, command and control centers, etc.

Features

* Input and output: Support up to 72 input and 72 output channels.

* Plug-in structure: input signal types: VIDEO,S-Video,VGA,YpbPr,DVI, HDMI,SDI,Fiber, HDBaseT; output signal types: HDMI,DVI,VGA ,YpbPr,VIDEO,HDBaseT,Fiber,SDI. Card design is easy for extension and change.

* Scalable seamless switching function.

* Support inline bidirectional IR and RS-232 control signal switching function (in conjunction with HDBaseT or FB board and corresponding transmission device).

* Support HDCP management, can encrypt and decrypt HDCP, ensure that the signal source displaces properly.

* Support EDID management, can store 8 groups of EDID data, allow reading the output device EDID or stored and apply it to any input cards, can send EDID codes to EDID storage area via the serial port, can read the current output EDID codes via the serial port.

* Have power-off memory function and scene memory function: have power-off site protection; can save and call 10 switching states.

* Support forward high-speed channel and embedded control signal separation switch modes.

* Support Full HD: HDPC: HDPC:1920X1200P@60_24bit, HDTV:1920X1080P@60_36bit.

* Luxury crystal buttons with luminous indicator function, the current switch information can be obtained directly from the LCD screen, easy to operate.

* Support 3D, HDMI 1.4, HDCP1.4, and DVI 1.0 protocol. Support high color depth, and up to 3.25Gbps rate.

* Have 2-Channel RS-232 communication interface.

* Have 1-way network port, can control remotely via Ethernet.

* Built-in universal power supply.

Specification

Model	TS-9272H
Interface
Input Card Quantity	9
Output Card Quantity	9
Input Route	72
Output Route	72
Support Input Card Type	TS-9208HR, TS-9208DR, TS-9208CR, TS-9208TR,
	TS-9208GR,TS-9208SR,
Support Input Card Type	TS-9208HC, TS-9208DC, TS-9208CC, TS-9208TC,
	TS-9208GC, TS-9208SC,
Interface Width	3.25Gbps, full digital
Serial Port Control
Quantity	2
Serial Control InterFace	RS-232, D type interface 9-pin D type interface
Baud Reate and Protocol	Baud rate: 9600, data bit: 8-bit,
	Stop bit: 1, white parity bit
Serial Port Control Structure	2 = TX, 3 = RX, 5 = GND
Ethernet Control
Ethernet Control Interface	RJ-45 female interface
Ethernet Control Protocol	TCP/IP
Ethernet Control Rate	Adaptive 10M/100M, full duplex or half duplex
Specification
Power Supply	~110V/60Hz or ~230V/50Hz, international
	adaptive power supply
Max Power Consumption	795W
Weight	30Kg
Storage and Usage Temperature	-20℃~+70℃
Storage and Usage Humidity	10%~90%
Dimension	16U
MTBF	30,000 hours
Size	484 x 404 x 710mm

Guarantee & Warranty

ITC promise the electronics yearly failure rate is less than 1%.

ITC guarantee all electronics of 3 years quality warranty.

ITC could supply 1% wearing spare parts free of charge.

ITC guarantee all loudspeakers of 6 months quality warranty.

All of quality complaint shall be attached with serial number, failure test report and photos.

All of the quality compliant shall be feedback with a solution within 48 hours.

ITC could supply circuit diagram documents for repair.

Packaging & Shipping

Full-sealing package of Products:

We adopt full-sealing bubble film+strech film+wood frame (or wood box). It will keep the moist from entering into the package to make the products rusted.
