Specifications
flake ice making machine1.Widely used
2.High quality compressor
3.Different capacity model
4.With CE approved
2014 High quality industrial flake ice making machine (BF-3000)
1 |
Model |
BF-3000 |
|
2 |
Daily output |
3 tons/day |
|
3 |
Weight |
1000kg |
|
4 |
Dimension |
Machine: 1800mm x 1250mm x 1400mm |
|
5 |
Noise |
55dB |
|
6 |
Compressor |
Brand |
Copeland (America) |
Model |
12HP |
||
Refrigeration capacity |
30.6KW |
||
Power |
12.33kw |
||
7 |
Power of cooling tower |
0.55 kW |
|
8 |
Power of cooling water pump |
2.2kw |
|
9 |
Power of reducer |
0.75 kW |
|
12 |
Power of recycling water pump |
0.18 kW |
|
10 |
Power of brine pump |
0.016 kW |
|
11 |
Thickness |
1.5mm~2.0mm, it is adjustable |
|
12 |
Temperature of the ice |
-8°C |
|
13 |
Power consumption |
about 75~80Kw.h to produce 1 ton ice per day |
|
14 |
Spray equipment
|
(Interior Carbon Steel Exterior Surface: Stainless Steel SUS304 |
|
15 |
Water pressure |
0.1MPa-0.4Pa |
|
Feature:
1.With Bitzer compressor from Germany, Danfoss Expansion valve from Denmark, Castal Solenoid valve from Italy, stainless steel water pump
2.The temperature of ice is lower and it can reach 8 degree below zero
3.Ice is dry and transparent, good looking shape, non-caked, good mobility and sanitary.
4.The thickness of flake ice is 1mm-2mm. No need to crush and can use at any time
5.Flake shape and no sharp edges, cannot destroy refrigerating products and it is beneficial for storage and transportation
6.Machines are very easy operated and energy-saving.
Our other main machines :
Pro-Taylor Refrigeration (Pengjiang) Firm is one of the leading refrigeration manufacturers in China, with our experience spanning over a decade. We have successfully exported our products to almost all over the world.
We have passed ISO quality management system and all our main products are CE approved. In addition, we have well-trained technicians who are also ready to help with checks in the Research & Development department, Quality Assurance and after-sales service.
1. OEM acceptable
2. 1 Year warranty and long life after-sale service
1. Lead time
-- Within 15 days after receive payment
2. Payment mode
--T/T, Western union, Paypal, L/C, Credit Card, ect
3. Packing
--Fiber wooden boxes, suitable for International transportation
