2016 Full HD IP camera NVR 32CH h.264 network video recorder
W What is the Feature of our Products?
Features
- 32chs IP camera inputs
- 16ch 720P realtime or 9ch 1080P realtime preview
- Record Solution: 5M/3M/1080P/960P/720P
-
Playback:
16ch 720P realtime or 9ch 1080P realtime or
4ch 3Mp @ 50/60FPS or 2ch 5Mp @ 25/30FPS - Audio:32ch input, Alarm:16ch in/4ch out
- 8*4T HDD
- NVR supports the popular brand TI, Hisilicon, Ambarella programs IPC and Dahua , Hikvision , Topsee , Axis , Canon, Dynacolor, Panasonic, Samsung, Sanyo , Sony and other IP cameras and the latest Onvif protocols
- VGA/HDMI output
- Multi-language Support(English, Finnish, French, German, Greek, Italian, Japanese, Polish, Portuguese, Russian, Spanish, Thai, Simplified Chinese, Chinese-Traditional, Turkish, etc)
- support P2P, cloud service
W What is the Specifications of our products?
2016 Full HD IP camera NVR 32CH h.264 network video recorder
| Model | NVR6832F |
| Video & audio input | |
| Network video input | 32CH |
| Video & audio output | |
| HDMI output | 800x600,1024x768,1280x1024,1440x900,720P,1080P |
| VGA output | 800x600,1024x768,1280x1024,1440x900,720P,1080P |
| CVBS output | NO |
| Audio output | 1PCS RCA Port( line level , impedance : 1kΩ) |
| Video & audio code and decode parameters | |
| Record resolution | D1/HD1/CIF/720P/960P/1080P/3M |
| Playback resolution | 720P 380/450FPS 1080P 100/120FPS 3MP 50/60FPS |
| Motion detection | Motion Detection Depend on NVR |
| Synchronously playback channels | 1/4/9/16CH |
| Record management | |
| Record & Snapshot mode | manual recording, regular recording, motion recording, alarm recording, events recording |
| Playback mode | regular playback,alarm playback,motion detection playback,events playback |
| Backup mode | regular backup, events backup, manual backup |
| Hard driver | |
| Mode | 8*SATA |
| HDD capacity | each port support max 4TB HDD |
| External port | |
| Voice intercom | 1PCS RCA Port(Level : 2.0Vp-p, impedance : 1kΩ) |
| Internet port | 1PCS RJ45 10M / 100M/1000M adaptive Ethernet port |
| USB port | 2*USB2.0 1*USB3.0 |
| Alarm input | 16 |
| Alarm output | 4 |
| Network Management | |
| Network protocol | NTP,SMTP,PPPoE,DDNS,FTP,ARSP,WIFI,3G |
| Other | |
| Power supply | AC100~240V |
| Power consumtion(without HDD) | ≤50W |
| Work temperature | -10℃--+55℃ |
| Work humidity | 10%--90% |
| Case | 2U |
| Size(W*L*H(cm)) | 04C:440*455*90mm 24C:440*447*90mm |
WWhat is the function of our product?
WIN 8 software: users-friendly, easy-operating.
Function: PAP, PIP, Fast playback, Slice recording, Cut and back up, Smart Search
PAP
you can zoom many areas and and view these zoomed areas at the same time
PIP PAP
View any other channel together, window can be dragged.
Slice Recording
In playback, the recording file can be sliced equally into smaller segmentation, which can be sliced equally again until the smallest segmentation. you can playback any segmentation. it save you much time to find a particular recording.
P Packaging &Shipping,Trade Terms
W Why choosing us?
1. More professional, better quality.
We engaged in software & hardware development, manufacturing and sales for security & safe products.( CCTV camera, IP camera, DVR, NVR ) for about 10 years.
2. OEM/ ODM service available.
Any your idea on camera we can help you to design and put in solution.
3.Strong Tech support.
* Presale: product consultation and solution design can be provided.
* After sale: We offer a 2years warranty, which includes maintenance and technical support for all the products. Within the warranty period, exchanges and free maintenance are provided. If any quality issues occur, please contact us for technical support via telephone, email, or any method available on our site.
* We can also provide customized products, project designs, our project partner like: Shell in Japan, Barranquilla Harbour in Colombia, Greece National Park..
4. Strict Quality Control :
All of our electronic parts will stay in constant temperature machines more than 48 hours before assembly, all products wiil be fully inspected before shipment.
with CE, ROHS, FCC approval.
