16ch 1080p nvr embedded nvr h.264 2U Dahua network cctv nvr
NVR3816
Feature
- Up to 4/8/16 channel with 1080p realtime live view
- H.264/MJPEG dual codec decoding
- Max 120fps@1080p, 240fps@720p,480fps@D1 preview & recording
- HDMI / VGA simultaneous video output
- All channel synchronous realtime playback, GRID interface
- Support Multi-brand network cameras: Dahua, Arecont Vision, AXIS, Bosch, Brickcom, Canon, CP Plus, Dynacolor, Honeywell, Panasonic, Pelco, Samsung, Sanyo, Sony, Videosec, Vivotech and etc.
- ONVIF Version 2.0 conformance
- 3D intelligent positioning with Dahua PTZ camera
- Support 8 SATA HDDs up to 32TB, 1 eSATA up to 16TB, 4 USB2.0
- Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS
Specification
| Model No. | NVR3804 | NVR3808 | NVR3816 |
| Main Processor | Dual-core embedded processor | ||
| Operating System | Embedded Linux | ||
| IP Camera Input | 4ch | 8ch | 16ch |
| Two-way Talk | 1 channel Input, 1 channel Output, BNC | ||
| Interface | 1 HDMI, 1 VGA | ||
| Resolution | 1920 * 1080, 1280 * 1024, 1280 * 720, 1024 * 768 | ||
| Display Split | 1/4 | 1/4/8/9 | 1/4/8/9/16 |
| OSD | Camera title, Time, Video loss, Camera lock, Motion detection, Recording | ||
| ompression | H.264 / MJPEG | ||
| Resolution | 1080P(1920 * 1080) / 720P(1280 * 720) / D1 (704 * 576/704 * 480) | ||
| Record Rate | 400/480fps@D1, 200/240fps@720P , 100/120fps@1080P | ||
| Bit Rate | 48 ~ 8192kbps | ||
| Record Mode | Manual, Schedule(Regular(Continuous), MD, Alarm), Stop | ||
| Record Interval | 1~120 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec | ||
| Trigger Events | Recording, PTZ, Tour, Alarm, Video Push, Email, FTP, Buzzer & Screen tips | ||
| Video Detection | Motion Detection, MD Zones: 396(22×18), Video Loss & Camera Blank | ||
| Alarm Input | 4ch | 8ch | 16ch |
| Relay Output | 6ch | ||
| Sync Playback | 1/4 | 1/4/8 | 1/4/8/16 |
| Search Mode | Time/Date, Alarm, MD & Exact search (accurate to second), Smart search | ||
| Playback Function | Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file, Next camera, Previous camera, Full screen, Repeat, Shuffle, Backup selection, Digital zoom | ||
| Backup Mode | USB Device / Network | ||
| Ethernet | RJ-45 port (10/100M/1000M) | ||
| Network Function | HTTP, TCP/IP, IPv4/IPv6, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPOE, DDNS, FTP, Alarm Server, IP Search(Support Dahua IP camera, DVR, NVS and etc.) | ||
| Max. User Access | 20 users | ||
| Smart Phone | iPhone, iPad, Android, Windows Phone | ||
| Internal HDD | 8 SATA ports (8HDDs or 6HDDs+1CD/DVD-RW), up to 32TB | ||
| External HDD | 1 eSATA port (Max 4 SATA HDDs), up to 16TB | ||
| USB | 4 ports (2 Rear), USB2.0 | ||
| RS232 | 1 port, For PC communication & Keyboard | ||
| RS485 | 1 port, For PTZ control | ||
| Power Supply | AC 100~240V, 50/60 Hz | ||
| Power Consumption | 40W | ||
| Working Environment | -10 ~+55°C / 10~90%RH / 86~106kpa | ||
| Dimension | 2U, 440mm × 460mm × 89mm | ||
| Weight | 6KG(without HDD) | ||
Our Services
Basic service
1. Any inquiry will be replied within 24 hours
2. Professional manufacturer. Welcome to visit our factory in ShenZhen City
3. OEM/ODM service is offered. Any of your designs are welcomed
4. High quality, fashionable designs, reasonable & competitive price, fast delivery date.
After-Sale Service
All DFD products enjoy the 3-year warranty and definitely will be free from maintenance within the warranty period.
Fast Delivery
Within 3 ~ 15 days for after payment cleared
Company Information
Shenzhen KingCCTV Technology Co., Ltd. is a high technology enterprise, engaged in software & hardware development, manufacturing and sales for security & safe products.
KingCCTV is headquartered in Futian District of Shenzhen, China. Our factory is in Yindafeng Industry Park of Longgang District of Shenzhen. As our business extended, in order to provide more products and better service, we established a Greece Branch on January of 2008, and established a USA Branch in Senoia GA on October of 2012. We mainly sell, develop and manufacture DVR, HDVR, NVR, CCTV Camera, IP Camera, PTZ camera, etc.
Our dominant customers
We have accomplished the following big projects:
CCTV Surveillance for Greece National Park
CCTV Surveillance for Jewish Historical Museum Amsterdam
CCTV Surveillance for Barranquilla Harbour in Colombia
CCTV Surveillance for Shell in Japan
World Wide Sales Network
Our products are extensively sold to more than forty countries and regions from 2004.
FAQ
Q: How long is the warranty?
A: 2 years warranty since delivered out.
Q: What's the MOQ?
A: Sample order, no MOQ limit.
Q: How long is the delivery time?
A: Around 3-15 working days upon receipts of payment.
Q: Why do you choose us?
A: Choose Shenzhen KingCCTV Technology Co., Ltd. ; Choose a qualified CCTV Products manufacturer!
We will try our best to find the products you need, we will provide you with the most satisfactory service. If you want to learn more, You can contact us. We also welcome you to visit our factory in Shenzhen.
