Home > Products > DVR Card > 2014 H 264 Hikvision 16 Channels Smart DVR Hardware Compression DVR Card(DS-4016HCI)
2014 H 264 Hikvision 16 Channels Smart DVR Hardware Compression DVR Card(DS-4016HCI)
- Shenzhen
- Money Gram Credit Card PayPal
You May Like
-
H 264 Hikvision 16 Channels Hardware Compression DVR Card(DS-4016HCI)
-
Hikvision DVR Card 16CH Smart Software DVR Card(DS-4016HCI)
-
Popular 4 Channels Real-time H.264 Video and Audio Compression DVR Card( DS-4004HCI )
-
New 4 Channels H.264 Realtime 4CH Hikvision DVR Card ( DS-4004HCI )
-
New 4 ChannelsH.264 Smart DVR Software Dvr Card Hikvision ( DS-4004HCI )
-
New 4 Channels Video and Audio CIF Hikvision Ds4004hci Hardware Dvr Card( DS-4004HCI )
Product Details
| Place of Origin | Guangdong, China | Brand Name | Hyking | |
| Model Number | HK-DS4016HCI |
Product Description
Specifications
16CH Hikvision DVR Card:DS-4016HCI-400fps(P)/480fps(N)
-D1 Resolution
-Smart DVR software for Hikvision DVR card
Hikvision dvr card 16CH :DS-4016HCI(Smart DVR software for Hikvision DVR card)
Cards are stackable to obtain 64 channels maximum
16 channels video and audio CIF (real time)
or 8 channels video and audio 4CIF (real time)
or 16 channel DCIF (real time)
or 16 channel 4CIF(not real time)
Features & Functions :
Real-time video and audio compression, no frame lost
4CIF preview resolution
Comply with PCI 2.2 standard , a PC can support up to 64 channels
Support WINDOWS 2000/XP operating system
Setable video quality and bitrate
Setable brightness , contrast , saturation and hue of video signal
Support motion detection
Support OSD , LOGO and MASK overlay
Support watermark technology
Support double encoding Specifications:
Specifications:
Item | Specifications | ||||
Video Format | PAL and NTSC | ||||
Video Input | 16 Ch BNC (1.0Vp-p, 75ohm) | ||||
Audio Input | 16 Ch BNC (2.0Vp-p, 1Kohm) | ||||
Preview Resolution | Resolution: 704*576(PAL),704*480(NTSC) | ||||
Video Compression | H.264, Support CBR, VBR; Frame: 25F/s(PAL)30F/s(NTSC) Output32kbps-1000kbps(CIF) or 70kbps-4000kbps(4CIF) | ||||
Compression Resolution | 4CIF704*576(PAL)704*480(NTSC) DCIF528*384(PAL)528*320(NTSC) 2CIF704*288(PAL)704*240(NTSC) CIF352*288(PAL)352*240(NTSC) QCIF176*144(PAL)176*120(NTSC) | ||||
Audio Compression | OggVorbis, Sample ratio is 16KHz, Output ratio is 16kbps | ||||
Power Consumption | Less than 7W | ||||
Working Temperature | -10--50 | ||||
Working Humidity | 10--90 | ||||
Dimension | 185mm*107mm | ||||
Computer Configuration (Recommend) | Mainboard: Intel 945 or 965 Chipset Memory: 512MB Display Adapter: Geforce Mx400/420/440 series or ATI Radeon 7000/7200/7500/8500/9000 X550series
| ||||
