Home > Auto, Motorcycle Parts & Accessories > Car Safety > Car DVR > Network Security Cctv Dvr H.264 8ch Network Dvr HK-S8008F

Network Security Cctv Dvr H.264 8ch Network Dvr HK-S8008F

Name: Network Security Cctv Dvr H.264 8ch Network Dvr HK-S8008F
Brand: Hyking
SKU: 127988015
Availability: InStock

Network Security Cctv Dvr H.264 8ch Network Dvr HK-S8008F thumbnail-1

Network Security Cctv Dvr H.264 8ch Network Dvr HK-S8008F photo-1

Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Place of Origin:

Guangdong, China

Brand Name:

Hyking

Model Number:

HK-S8008F

Contact Supplier Request Quote Chat Now

Shenzhen KingCCTV Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Guangdong, China

Brand Name Hyking

Model Number HK-S8008F

Specifications

h.264 security cctv dvrHK-8008F
1).Display&Record: 200fps(P)/240fps(N),
2).352x288,remote control
3).Looping&matrix function

8 channel h.264 network security cctv dvr h.264 8ch network dvr HK-S8008F

Function Standalone HK-S8004F/S8008F/HK-S8016F

(1) The video compression is H.264, supports VBR as well as CBR, selectable video picture quality
(2) Adopt TI and Philips Chipsets,provide better and clear video picture quality
(3) Adopt high performance criterion of embedded real-time multiple operating system (RTOS)
(4) Looping function and matrix functions
(5) Support TCP/IP protocols(support ARP, RARP, IP, TCP, PPPOE, DHCP, etc.)
(6) Support PAL/NTSC4. 43/NTSC3. 58 video signals
(7) Recording resolution:352x240 (NTSC),352x288 (PAL)
(8) 6 kinds of record image quality for choosing
(9) Support several channels playback in same time.
(10) Support PS/2 Mouse
(11) Support: Manual video, timing video, motion detection and warning video, support the categorized search of video
(12) USB Port:3*USB 2.0 port for backup
(13) Client PC can record compressed data stream, support record audio and video signals into the computer directly through Internet
(14) Support 8*SATA
(15) Provides USB 2.0 backup interface on front and back of DVR for hard disk, CD-R or DVD-R, supports backup through network

Model/Item	HK-S8004F	HK-S8008F	HK-S8016F
Compression Format	H. 264, supports VBR as well as CBR
Operation System	Embedded real-time operating system (RTOS)
Video Input	BNC x 4,1.0VP-P,75¦¸	BNC x 8,1.0VP-P,75¦¸	BNC x 16,1.0VP-P,75¦¸
Video Output	1 BNC video,1 VGA,8 chs loop		1 BNC video,1 VGA, 16chs loop&matrix
Audio Input	BNCx4, 10K, Vp-p=2.0V	BNCx8, 10K, Vp-p=2.0V	BNCx16, 10K, Vp-p=2.0V
Audio Output	BNCx1, 10K, Vp-p=2.0V,Loop		BNCx1, 10K, Vp-p=2.0V,matrix
Audio Compression Format	Separatedly compress each audio and video signal stream, the compressed audio standard adopts G. 722
Display Frame Rate	BNC: 704576 (PAL) / 704480 (NTSC) VGA: 800*600
Record Resolution	352288(PAL) 352240 (NTSC)
Display Frame Rate	100fps(PAL) 120fps(NTSC)	200fps(PAL) 240fps(NTSC)	400fps(PAL) 480fps(NTSC)
Recording Frame Rate	100fps(PAL) 120fps(NTSC)	200fps(PAL) 240fps(NTSC)	400fps(PAL) 480fps(NTSC)
Recording Mode	Support: Manual video, timing video, motion detection and warning video, support the categorized search of video
Motion detection function	Each video can set up multiple dynamic measuring areas, support full screen shielding
Network Recording	Support 4 to 16 channels recording to PC through network, each video parameter can set up alone
USB	USB2.0
Alarm Input	NO or NC, 4CH	NO or NC, 8CH	NO or NC, 9CH
Alarm Output	2CH	4CH	4CH
Recording Mode	manual video,timing video,motion detection video and warning video
Network Interface	RJ45 10M/100M Ethernet Interface
PTZ Control	RS485
HDD	Support 8 SATA
Local playback	accurate time playback, search playback the contents of manual video, timing video, motion detection video and warning video
Backup	USB2.0 / High Speed SATA / Remote Backup
Storage Temperature& Humidity	-20--65 °C; / 10-90% RH (No Condenser)
Operation Temperature& Humidity	-10--55 °C; / 10-90% RH (No Condenser)
Power Adapter	220/110V, 50/60HZ
Power Consumption	20W (without hard disk)	25W (without hard disk)	30W (without hard disk)
Dimension (L x W x H)	440mm420mm100mm
Weight	Gross weight:10kg ; Net weight:8kg

Application:

H.264 compression, Can Display up to 16 Cameras, Support 4 channel playback simultaneously Recommended installation areas are Securities Companies, Change Booths, Pawnshops, Jewerlers, Galleries, Exhibition Halls, Department Stores, Convenience Stores, Discount Offices, Hospitals, Police Stations, Subway Stations, Airports, Banks etc.
