Network Security Cctv Dvr H.264 8ch Network Dvr HK-S8008F
- Shenzhen
- Money Gram Credit Card PayPal
You May Like
-
High Quality16 Channel HD-SDI Full-HD Cost-effective Compression Card
-
High Quality4 Channel HD-SDI Full-HD Cost-effective PCI-E Compression Card
-
Full D1 Hikvision Hardware Compression DVR Card
-
High Quality Hikvision Hardware Compression DVR Card
-
High Performace H.264 Software Compression DVR Card
-
High Quality DVR Card High Performance Software Compression PCI DVR Video Card Real Time Dvr Board
Product Details
| Place of Origin | Guangdong, China | Brand Name | Hyking | |
| Model Number | HK-S8008F |
Product Description
Specifications
h.264 security cctv dvrHK-8008F1).Display&Record: 200fps(P)/240fps(N),
2).352x288,remote control
3).Looping&matrix function
8 channel h.264 network security cctv dvr h.264 8ch network dvr HK-S8008F
Function Standalone HK-S8004F/S8008F/HK-S8016F
(1) The video compression is H.264, supports VBR as well as CBR, selectable video picture quality
(2) Adopt TI and Philips Chipsets,provide better and clear video picture quality
(3) Adopt high performance criterion of embedded real-time multiple operating system (RTOS)
(4) Looping function and matrix functions
(5) Support TCP/IP protocols(support ARP, RARP, IP, TCP, PPPOE, DHCP, etc.)
(6) Support PAL/NTSC4. 43/NTSC3. 58 video signals
(7) Recording resolution:352x240 (NTSC),352x288 (PAL)
(8) 6 kinds of record image quality for choosing
(9) Support several channels playback in same time.
(10) Support PS/2 Mouse
(11) Support: Manual video, timing video, motion detection and warning video, support the categorized search of video
(12) USB Port:3*USB 2.0 port for backup
(13) Client PC can record compressed data stream, support record audio and video signals into the computer directly through Internet
(14) Support 8*SATA
(15) Provides USB 2.0 backup interface on front and back of DVR for hard disk, CD-R or DVD-R, supports backup through network
Model/Item | HK-S8004F | HK-S8008F | HK-S8016F |
| Compression Format | H. 264, supports VBR as well as CBR | ||
| Operation System | Embedded real-time operating system (RTOS) | ||
| Video Input | BNC x 4,1.0VP-P,75¦¸ | BNC x 8,1.0VP-P,75¦¸ | BNC x 16,1.0VP-P,75¦¸ |
| Video Output | 1 BNC video,1 VGA,8 chs loop | 1 BNC video,1 VGA, 16chs loop&matrix | |
| Audio Input | BNCx4, 10K, Vp-p=2.0V | BNCx8, 10K, Vp-p=2.0V | BNCx16, 10K, Vp-p=2.0V |
| Audio Output | BNCx1, 10K, Vp-p=2.0V,Loop | BNCx1, 10K, Vp-p=2.0V,matrix | |
| Audio Compression Format | Separatedly compress each audio and video signal stream, the compressed audio standard adopts G. 722 | ||
| Display Frame Rate | BNC: 704*576 (PAL) / 704*480 (NTSC) VGA: 800*600 | ||
| Record Resolution | 352*288(PAL) 352*240 (NTSC) | ||
| Display Frame Rate | 100fps(PAL) 120fps(NTSC) | 200fps(PAL) 240fps(NTSC) | 400fps(PAL) 480fps(NTSC) |
| Recording Frame Rate | 100fps(PAL) 120fps(NTSC) | 200fps(PAL) 240fps(NTSC) | 400fps(PAL) 480fps(NTSC) |
| Recording Mode | Support: Manual video, timing video, motion detection and warning video, support the categorized search of video | ||
| Motion detection function | Each video can set up multiple dynamic measuring areas, support full screen shielding | ||
| Network Recording | Support 4 to 16 channels recording to PC through network, each video parameter can set up alone | ||
| USB | USB2.0 | ||
| Alarm Input | NO or NC, 4CH | NO or NC, 8CH | NO or NC, 9CH |
| Alarm Output | 2CH | 4CH | 4CH |
| Recording Mode | manual video,timing video,motion detection video and warning video | ||
| Network Interface | RJ45 10M/100M Ethernet Interface | ||
| PTZ Control | RS485 | ||
| HDD | Support 8 SATA | ||
| Local playback | accurate time playback, search playback the contents of manual video, timing video, motion detection video and warning video | ||
| Backup | USB2.0 / High Speed SATA / Remote Backup | ||
| Storage Temperature& Humidity | -20--65 °C; / 10-90% RH (No Condenser) | ||
| Operation Temperature& Humidity | -10--55 °C; / 10-90% RH (No Condenser) | ||
| Power Adapter | 220/110V, 50/60HZ | ||
| Power Consumption | 20W (without hard disk) | 25W (without hard disk) | 30W (without hard disk) |
| Dimension (L x W x H) | 440mm*420mm*100mm | ||
| Weight | Gross weight:10kg ; Net weight:8kg | ||
Application:
H.264 compression, Can Display up to 16 Cameras, Support 4 channel playback simultaneously Recommended installation areas are Securities Companies, Change Booths, Pawnshops, Jewerlers, Galleries, Exhibition Halls, Department Stores, Convenience Stores, Discount Offices, Hospitals, Police Stations, Subway Stations, Airports, Banks etc.
