CCTV PTZ Tester (Model No: HK-TM801) Equipment for PTZ

CCTV PTZ Tester (Model No: HK-TM801) Equipment for PTZ thumbnail-1
CCTV PTZ Tester (Model No: HK-TM801) Equipment for PTZ photo-1
US$ 85 - 125 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
KingCCTV
Model Number:
HK-TM801
Contact Supplier Request Quote Chat Now
Shenzhen KingCCTV Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name KingCCTV
Model Number HK-TM801

Specifications

CCTV PTZ Tester (Model No: HK-TM801) Equipment for PTZ
2.8"TFT-LCD
Lithium Ion Polymer Battery support 11 hours
easy use

CCTV PTZ  Tester (Model No: HK-TM801) Equipment for PTZ



1) 2.8"TFT-LCD, LCD Brightness/Contrast/Color Saturation adjustable;

2) PTZ controller,PTZ data analyst, PTZ address scanning;

3) NTSC/PAL auto display, Video Level testing;

4) NTSC/PAL colorbar generator,UTP cable tester;

5) Lithium Ion Polymer Battery support 11 hours working time.



CCTV PTZ Tester (Model No: HK-TM801) Equipment for PTZ       CCTV PTZ Tester (Model No: HK-TM801) Equipment for PTZ  CCTV PTZ Tester (Model No: HK-TM801) Equipment for PTZ         CCTV PTZ Tester (Model No: HK-TM801) Equipment for PTZ



Application:
1) CCTV system installation and maintenance
2) Dome camera and All in one camera testing
3) The CCTV transmitting channel testing
4) PTZ controller



Features:

  • 2.8"TFT-LCD , 960£¨H£© x 240£¨V£©resolution
  • Adjustable brightness, contrast, color of LCD
  • Video Level testing, video signals measured in IRE or mV
  • Automatically identify and adapt the video mode of NTSC and PAL
  • Colorbar Video signal generator, transmit/receive colorful images
  • Support more than twenty kinds of PTZ controller protocols. For example, PELCO-P, PELCO-D, SAMSUNG etc.
  • Capture the PTZ protocol to assist the setting personnel to find out the control protocol and therefore easily target the problematic equipment.
  • Support RS232 and RS485 interface, the rate 150-19200bps
  • Powerful in testing LAN cable, measuring the connecting status and displaying the sequence of connection
  • PTZ(P/L & Zoom) Control: Control the status of P/L, zoom in/out the camera, adjust the aperture, foci and setting parameters, run and call the preset.
  • PTZ address scanning, search up the ID of PTZ camera
  • Lithium Ion Polymer Batteries(3.7V DC2000mAh), more reliable, and work 11 hours
  • Easy to use that the train is almost unnecessary

Specifications:

Model/Item
 HK-TM801 CCTV Security Tester
Video Test
Signal mode NTSC/PAL (Auto Adjust)
Display 2.8 inch TFT-LCD ,960 x 240 resolution
LCD adjust Adjustable brightness, contrast, color of LCD
Video IN/OUT 1 channel BNC Input & 1 channel Output
Video Output Mode 1.0 Vp-p
Video Level test
Level test Video signals measured in IRE or mV
Power Output(Optional)
Power output DC12V, 1A
Audio Test(Optional)
Audio input 1 channel Audio input
PTZ controller
Communication RS232, RS422 simplex and RS485
PTZ Protocol Compatible with more than 20 protocols such as PELCO-D/P, Samsung, Panasonic, Lilin, Yaan, etc.customized
Baud Rate 150,300,600,1200,2400,4800,9600,19200bps
Video Signal Generation
Color bar generation Output 1 channel color bar video signal for testing monitor
UTP CABLE TEST
UTP cable test Test UTP cable connection state and display in the screen. Read the number of the test box.
PTZ data Capture and display
PTZ Data Test Capture and Analyze the PTZ data sent from controlling device
PTZ address scanning
PTZ address scan Search up the ID of PTZ camera
POWER
Power Adapter DC5V, 2A
Battery 1 pcs Lithium Ion Polymer Batteries, 3.7V DC2800mAh
Rechargeable 4 hours recharging time, work for 15 hours
Low Consumption Sleeping mode, display battery power state
Other Parameters
Work Temperature -10 °C---+50 °C;
Work Humidity 30%-90%
Dimension/Weight 166mmx95mmx48mm/293g

CCTV PTZ Tester (Model No: HK-TM801) Equipment for PTZ     CCTV PTZ Tester (Model No: HK-TM801) Equipment for PTZ



 CCTV PTZ Tester (Model No: HK-TM801) Equipment for PTZ
