Electric high and low temperature test box with high quality for cheap price
- 1000 Set / Sets per Month
- shanghai
- T/T L/C D/P D/A Credit Card PayPal
- HVAC DCV System Mini USB CO2 Detector CM01
- HVAC DCV System Wall-Mount CO2 Transmitter Controller AM6208W
- ISO4406、NAS1638 Measurement of oil contamination level detection online device
- Equipment For Measuring flash point ISO2592, ASTM D92 Laboratory Test Equipment
- ADDITION Laboratory Equipment for Measuring Viscosity ASTM D445
- Smart Moisture Meter Coffee bean moisture meter MG-Pro
Product Details
Place of Origin: | Jiangsu, China | Brand Name: | ronghua | Model Number: | DW GD(J)W-100(225,500,101,100) |
Product Description
General Introduction
Product use:
Electric high and low temperature test box with high quality for cheap price
is used to check and determine the electrical, electronic, automotive electronics, materials and other products in the high temperature environment under the conditions of storage and use of the applicab-ility, suitable for schools, factories, military and scientific research units.
Box structure:
Adopting the NC machine tool processing molding, beautiful appearance, and the handle with no reaction, simple operation.
Inner chamber using imported advanced stainless steel (SUS304) mirror panel, outside the box body liner is made of A3 steel plate spray, an increase of appearance and cleanliness.
A large observation window attached to the lights keep bright, and the use of heating body embedded toughened glass, ready to clear observation in the situation.
The left box test holes with a diameter of 25mm or 50mm, for the external test power line or signal line.
Controller:
Temperature control adopts imported touch button type instrument, simple operation set. Data and test conditions after input controller
With a locking function, avoid the human touch and temperature change value.
Has the function of automatic P.I.D calculus can be immediately modified conditions of temperature changes, the temperature control is more precise and stable;
Optional printer.
Freezing and wind cycle system:
Refrigerator using the French original "Taikang" closed compressor.
The design unit or two yuan cryogenic loop refrigeration system using the system.
The multi blade fan powerful air circulation, to avoid any dead, makes the temperature distribution within the test area evenly.
The wind road cycle air return design, wind pressure, wind speed meets the test standard, and can make the door instantaneous temperature stabilization time.
Heating, cooling, completely independent system can improve the efficiency, reduce testing cost, increase service life, reduce failure rate.
Standard:
GB/T2423.1-2006 GB/T2423.2-2006
Technical Parameters
model | DW | DW | DW | DW | DW | |||
Studio size D*W*H | 450×450×500 | 500×600×750 | 700×800×900 | 1000×1000×1000 | 1000×1000×1300 | |||
size | 1050×880×1650 | 1100×1050×1900 | 1400×1150×2050 | 1600×1450×2150 | 1600×1450×2450 | |||
performance index
| temperature range
| A:-20℃~150℃ ,B:-40℃~150℃ ,C:-60℃~150℃ ,D:-70℃~150℃ | ||||||
Fluctuation / uniformity
| ≤±0.5℃/≤+2℃-3℃ | |||||||
Heating time
| -20℃~100℃ about 35min | -40℃~100℃about 45min | -70℃~100℃about 55min | |||||
The cooling time
| 20℃~-40℃about 50min | 25℃~-60℃about 65min | 25℃~-70℃about 80min | |||||
Temperature and humidity control system
| controller
| The import of LED digital P, I, D+S, S, R. integrated microcomputer controller
| ||||||
Precision range
| Temperature setting precision: - 0.1 DEG C, indicating accuracy: temperature: + 0.1 + - 0.1 DEG C, resolution
| |||||||
Temperature and humidity sensor
| Platinum resistance PT100 /MV.
| |||||||
heating system
| The whole system independently, Ni Cr alloy electric heater
| |||||||
refrigeration system
| Totally enclosed fan cooled single-stage compression refrigeration / original French "Taikang" / tefc cascade compression refrigeration
| |||||||
circulatory system
| High temperature low noise air conditioning type motor, multi vane centrifugal wind wheel
| |||||||
The use of materials
| External material
| High quality carbon steel, phosphating electrostatic spray processing of /SUS304 stainless steel matte line hairline processing
| ||||||
Internal material
| High quality SUS304 stainless steel mirror plate
| |||||||
material
| Polyurethane hard foam / superfine glass fiber cotton
| |||||||
Frame insulation
| Double high temperature aging silicon rubber sealing strip
| |||||||
Standard configuration
| Multilayer heating and defrosting of lighting glass to inspect 1 sets of sample frame 2, the test lead hole (25,50mm) 1
| |||||||
safeguard
| Leakage, short circuit, over temperature, motor overheating, compressor overpressure, overload, overcurrent protection
| |||||||
timer
| 0.1~999.9(S,M,H)adjustable | |||||||
supply voltage
| AC380V±10% 50±0.5Hz three-phase five wire
| |||||||
The use of environmental temperature
| 5℃~+30℃ ≤80%R·H | |||||||
Note: 1, "GDW" for the high and low temperature test box type "DW" for the low temperature test box "GDJW" for the high temperature test box 2, the above data are at ambient temperature (QT) of 25 DEG C, the studio is measured under the condition of no load 3, according to the user's specific requirements of non-standard type of high and low temperature, and low temperature test chamber.
|
Why do you choose us?
12 months guarantee period from machine arriving date.
Aboudant spare parts in stock are available to provide.
Our technicians could be dispatched for overseas.
packing:wooden
Factory Overview
Chang Zhou rong hua Instrument Manufacturing Co., Ltd., is the larger instrument manufacturing company. Enterprises through the ISO9001 quality system certification, won the Jiang su Province quality credit
Enterprises (products) title. In recent years, gradually expand the scale of enterprises, technical force is abundant, believe in science and technology development and innovation is the survival and development of enterprises
Life force. The products are sold throughout the country, many times in the Ministry of health, the State Education Commission, the Ministry of agriculture and the world bank loan project bidding. And a large number of exports in Southeast Asia, Europe and America etc.
Country. All the staff always adhere to the "unity, pragmatic, pioneering and innovative" spirit of enterprise, based on the user oriented, scientific research institutions, national universities in China, China
International market, quality and efficiency, reputation and market share.
The main products are: Changzhou salt fog test box Changzhou constant temperature and humidity box of high and low temperature box at low temperature and high humidity test chamber high low temperature test box price salt fog test box
, high and low temperature test box, high-temperature oven, oven, high and low temperature heat test box, low temperature test box, constant temperature and humidity test chamber, temperature shock test chamber, fungus test box,
Fungal alternating test box, aging test box, ventilation aging test box, UV resistant climate chamber, xenon lamp weather resistance test box, swing pipe rain test device, waterproof
Test box, dust test chamber, antirust oil damp heat test box, ozone aging test box, alternating high and low temperature test chamber, incubators, oscillator, constant temperature water bath
Analysis, blender, electric sets, centrifuge, laboratory, environmental protection equipment and so on.
The company in line with high quality, high efficiency, the spirit of development, follow the "quality of survival, technology and development, market-oriented, service for the purpose of" business
The concept, to high-quality products, reasonable price, considerate service to every customer.
Is willing to cooperate wholeheartedly with the community, common development!
Parts In Line
1,Are you a factory or trading company?
A:We are a factory.
2,How can I get some samples?
A:We are honored to offer samples for your evaluation.
3,Where is your company location?
A:Our company is in Changzhou,Jiangsu province,China ,near Shanghai.We are happy to invite you to our company.
