Help CenterLaboratory or Industrial UV Weather Resistance Test Box
Related Products
-
2016 New Laboratory Centrifuge With High QualityUS$ 25 - 35MOQ: 1 Set -
2016 New Crude Oil Centrifuge With High QualityUS$ 25 - 35MOQ: 1 Set
-
2016 New Small Sludge Decanter Centrifuge With High QualityUS$ 25 - 35MOQ: 1 Set
-
2016 New Mini Palm Centrifuge With High QualityUS$ 25 - 35MOQ: 1 Set
-
2016 New Meteor Handheld Centrifuge With High QualityUS$ 25 - 35MOQ: 1 Set
Product use
This series of products applicable to non-metallic materials resistant to sunlight and artificial light aging test.
Box Structure
Adopting the NC machine tool processing molding, beautiful appearance, the box cover is a two-way clamshell, easy to operate.
The bladder imported advanced stainless steel plate, outer box using A3 steel plate coating, increase the appearance and cleanliness.
Heating method for bladder type heat sink, heating speed, uniform temperature distribution.
Drainage system using the back vortex type and U type deposition drainage device, convenient for users to clean.
Control system
By connecting the blackboard temperature sensor using Blackboard temperature meter control heating temperature is more stable.
Radiometer probe with a fixed, each without handling.
The amount of radiation with high precision display and special ultraviolet radiation measurement (optional).
The irradiance is not greater than 50W/m2
Light and condensation can be controlled independently can cycle control.
Independent control of time light and condensation and alternate cycle control time can be set arbitrarily within 1000 hours.
Standard
GB/T16422.3-1997
GB/T16585-96
model |
ZN-P |
|
Studio size D×W×H |
450 x 1170 x 500 mm |
|
|
Support sample number
|
75×150 mm about 40 pieces 75×300 mm about 20 pieces |
|
Size D×W×H |
580 x 1280 x 1350 mm |
|
performance index |
Fan Gang temperature |
RT+l0℃- 70℃ |
|
Humidity range |
90-98%R.H |
|
Light center distance |
70mm |
|
The sample and the lamp center distance |
50mm |
|
Lamp wattage |
40W |
|
Effective radiation area |
900×210 mm |
Temperature and humidity control system |
UV wavelength |
290mm - 400mm UV-A, UV-B. UV-C(When ordering instructions) |
|
Blackboard temperature |
40℃- 65℃ |
|
Temperature and humidity controller |
Ni.ED P.I.D+S.S.R. digital integrated microcomputer controller |
|
Light heating system |
The whole system independently, nickel chromium alloy electric heating type heater |
|
Condensation heating system |
All stainless steel shallow surface evaporative humidifier |
|
Water supply system |
The humidifying water supply automatic control |
|
Exposure mode |
The condensation of moisture exposure, light radiation exposure |
safeguard |
Leakage, short circuit, over temperature, water shortage, over-current protection, power failure memory controller |
|
|
Note: (L) AUV for the simulation of rain spray function
| ||
