Help CenterLGZ Scraper Bottom Discharge Automatic Centrifugal Centrifuge Separator Machine for Pharmaceutical
Related Products
-
Chemical Use Bottom Discharge Scraper Automatic CentrifugeUS$ 20,000 - 50,000MOQ: 1 Set -
Scraper CentrifugalUS$ 20,000 - 50,000MOQ: 1 Set
-
Bottom Discharge Scraper Automatic Centrifugal for Chemical/pharmaceutical UseUS$ 20,000 - 50,000MOQ: 1 Set
-
Gk Series Horizontal Wide Scraper Full Auto Centrifugal MachineUS$ 39,800 - 39,800MOQ: 1 Set
-
LGZ Scraper Bottom Discharge Automatic CentrifugalUS$ 20,000 - 50,000MOQ: 1 Set
Main features:
PLC control is applied with programs which can be designed,automatic operation can be realized even without worker at the physical field feeding,preliminary filter,washing,precise filter can be supervised during the full procedure.
Started by frequency modulator,the start of the machine is stable the separation coefficient is adjustable.
Power consumption brake,non-contact type brake mode,no frictional powder pollution.
The full sealing parts have applied silicon rubber or fluorine rubber.Nitrogen protection system is applied in the inside part of the centrifugal machine,sealing and explosion prevention requirements can be realized.
Reasonable structure design ,on line washing system(spraying system)guarantee the clean extent requirement and GMP norm can be corresponded to.
Pneumatic system has been applied in automatic operation parts to keep sanitary and clean.
Frequency emission material procedure control.
Pneumatic auxiliary scraper can be chosen,there is no remaining jam in the rotating drum after discharge.
Non foundation installation,concise structure,beautiful appearance,convenient washing and cleaning.
Design of vibration reduction & separation is scientific and reasonable,balance pieces and imported high precision liquid type resistance.vibration separation system have been applied,the vibration of the machine is fully absorbed by vibration separation system,there is no shock disturbance for the foundation ground or near by environment .
Balance plate of the device foundation can be used for operation platform,which makes operation and maintenance convenient.
Safety protection:inspection of rotational speed,over vibration protection,protection for discovering,over charge or over hear protection of the motor,double electrical control for rotation of scraper and lift machinery machinery,combined lock for the scraper and rotating drum.
Standard manufacturing form.
Structure:Feeding pipe,washing pipe,observation window,exhaust hole lightening hole have been applied in the turning over cover of the outshell ,the sealing structure,rotating drum and outshell,turning over cover are all made of stainless steel(SUS304),machine chassis parts are made of cast material ,The surface is covered with stainless steel,The rotating drum,inside and outside surfaces of the outshell,the exposed parts of the machine have all been polish treated.
1.All tightening parts are made of stainless steel.
2.Electrical material procedure control.
3.PLC control is applied.
4.Transmission and brake:normal motor explosion prevention motor+frequency modulator+power consumption brake.
5.Pneumatic system.
6.Non foundation form balance pieces+imported high precision liquid type resistance vibration separation system.
Device for choice:
1.washing & cleaning spray system.
2.Nitrogen protection system
3.Frequency emission material procedure control.
4.PLC control is applied.
5.Hydraulic operation system.
6.Pneumatic auxiliary scraper.
7.Choose the corresponding stainless steel(such as SUS304,316,316L,321,TA2).according to the customer's erosion proof requirement for separated material.
Technical specifications:
