ENERGY SAVING PSA NITROGEN GENERATING PLANT PRICE
PSA NITROGEN GENERATOR TECHNICAL INDEX
Nitrogen flow: 1~4000Nm3/h (20℃,101.325Kpa )
Nitrogen purity: 97~99.9999%
Nitrogen pressure: 0.05~1.0Mpa
Atmosphere dew point: -70 ℃~-45 ℃
PSA NITROGEN GENERATOR FEATURES
PSA NITROGEN GENERATOR WORKING PRINCIPLE
PSA, short for Pressure Swing Adsorption, is a kind of the advanced technology for air separation,and it
plays an irreplaceable role in nowadays on-site gas supplying.
Carbon molecular sieve (CMS) has obvious adsorption differences to nitrogen and oxygen, there are many
tiny holes inside the CMS, under certain pressure, the tiny holes have different adsorptioncapacity to
nitrogen and oxygen. When air pressure increases, CMS adsorbs oxygen and produces nitrogen, when air pressure drops to normal condition, CMS desorbs oxygen and regenerates itself.
PSA nitrogen generation usually adopts two adsorption towers, which is filled with the CMS, when one adsorbs oxygen and produces nitrogen, the other desorbs oxygen and makes regeneration. This alternate process
constantly produces nitrogen.
PSA NITROGEN GENERATOR FLOW CHART
PSA NITROGEN GENERATOR TECHNICAL DATA
Packaging: 1.Standard Export Wooden Package with Necessary Protection
2.We can packing also based on customer's special request
Shipping: By sea
The more information you kindly tell us,the better professional service we provide for you !
A. What is the gas source you currently use?(cylinder/dewar/liquid gas/other)
B. Gas consumption?(Nm3/h,L/min)
C. Required gas pressure?
D. Required gas quality?(eg:Maximum oxygen percentage,Maximum moisture content,etc)
Our HYT team will design and customized relate technical project and provide the suitable selection and quotation for you in time.
