Help CenterCN8 Series Multi-function Digital Counter
US$ 22 - 30
MOQ: 5 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
SOMMY
Model Number:
CN4/7/8/80
Payment & Shipping
Payment Methods:
Port of Shipment:
Zhongshan port/Guangzhou port/Shenzhen port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
CN80 Series Multi-function Digital CounterUS$ 23 - 30MOQ: 5 Pieces -
High Speed CT Series Multi-function Counter/timerUS$ 12 - 25MOQ: 1 Piece
-
Digital Display Counter Meter With 2 Alarms Output / Timer DigitalUS$ 12 - 25MOQ: 1 Piece
-
Multi-function Digital Tally CounterUS$ 11 - 15MOQ: 2 Pieces
-
6 Digit Small Digital Electric Counter Meter With Timing FunctionUS$ 15 - 21MOQ: 2 Pieces
Place of Origin
Guangdong, China
Brand Name
SOMMY
Model Number
CN4/7/8/80
Features:
1.Counting speed 1CPS/30CPS/1KCPS/10KCPS
2. Power fail memory function, 3 alarm outputs, 9 kinds of timing range selectable
3. 6 digit product counting/timing/batch counting
4. Bach counting function, batch alarm output
5. For rotary encoder signal input, no need to connect pull-up resistor. With Mobdbus 485 communication interface
6. Applied to light industry, machinery, packing, food industry etc for counting length, product quality etc.
7. Panel mounting size: 3: 36HX72WX80L 4: 48HX48WX90L 7: 72HX72WX90L 8: 96HX48WX90L
Technical Specification
| Power supply | 100~240V AC/DC | Display | Dual line 6 digit LED |
| INA,INB input frequency | 1Hz,30Hz,1KHz,5KHz,10KHz is selectable | Auxikary power | 12DC+-10%<=100mA |
| Input pulse width | INA,INHIBIT,RESET,BATCH REST,10ms or 20ms is optional | Data storage | 10 years |
| Input | voltage input:input impedance is 5.4kΩ H 5-30VDC L:0-2VDC Non-voltage input:max short-circuit impedance:1 kΩ,residual voltage:max 2VDC open-circuit impedance:Max 100kΩ | ||
| One-short output | 10/50/100/200/500/1000/2000/5000ms | ||
| Relay output capacity | NO:250VAC 3A impedance NC250VAC 2A impedance | ||
| Coefficient setting | 0.00001-999999 can be set freely | ||
| Work temperature | -10~50degree(Non-freezing) | ||
| Dielectric strength | 2000V AC 50/60Hz 1 minute | ||
| Interference (AC power) | +-2kv interferenced by square wave generator(pulse wideth 1us) | ||
