Measuring Sensor Indicator
US$ 11 - 18
MOQ: 5 Pieces
Key Specifications
Get Latest Price
Place of Origin:
China
Brand Name:
SOMMY
Model Number:
SF4-R2B
Payment & Shipping
Payment Methods:
Port of Shipment:
Zhongshan
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Place of Origin
China
Brand Name
SOMMY
Model Number
SF4-R2B
Economic sensor indicator,control indicator,digital indicator
Features:
- Optional mAMvVRtTCRTD signal input
- Free setting display range
- Well anti-jamming
- 2 alarms output
- Dimensions(mm):48WX48HX105L , 48WX96HX112L , 48HX96WX100L , 96WX96HX118L , 72WX72HX112L
Ordering Code
Model |
Input signal |
Alarm |
Auxiliary Power |
SF4 -A10 |
DC 4-20mA DC 0-10V Other:0-400Ω,DC0-50mV can be ordered |
No |
No |
SF4 –R2B |
2 |
DC24≤30mA |
|
SF 4–A10-T |
TC:K, J, E, T RTD:Cu50,Cu100 |
No |
No |
SF 4–R2B-T |
2 |
DC24≤30mA |
Technical Specification
Testing function |
SF 4–R2B |
DC 0~10V or 4~20mA |
Ambient temperature |
0-50°C |
SF4 –R2B |
0-400Ω |
Humidity |
45~85%RH |
|
SF 4–R2B |
DC 0~50mV |
Sampling rate |
2.5 times/s |
|
Power supply |
SF6/7/8/9/16/80:AC110/220V±10% SF4:AC/DC 100~240V |
Accuracy |
0.5%F.S±2 digit |
|
Alarm output |
AL1:AC 1A/250V AL2: AC 3A/250V |
Total current |
<30mA(220VAC) |
|
Display range |
-1999~4000 |
Auxiliary Power |
24V |
|
