Specifications
1.automatic plastic bag- making packaging machine2.bag forming,filling,sealing
3.highly quality
4.CE,ISO
1.Application:
The packaging machine can be euqipped with different weighter and filling system for various granule, powder and liquid products, packaging such as peanuts, candies, cookies, chips, rice, sugar, beans, dried fruit, pet food, ground coffee, milk, detergent powder, shampoo, ketchup, spices ,etc.
2.Advantage:
1. Machine fully controlled by Siemens or Omron PLC & Touch-Screen
2. Capacity per minute automaticlly displayed on Touch screen
3. Film transporting system and horizontal Jaw motion both drived by Panasonic
3.Technical Specification:
Bag type |
Pillow-type bag;Gusseted bag (Option) |
Speed |
50 to 100 bags/min |
Bag Length |
50 to 340mm (2.0 to 13.4in) |
Bag Width |
80 to 260mm (3.1 to 10.3in) |
Reel Film Width |
≤540mm (21.2in) |
Film thickness |
0.04-0.12mm (40-120mic.) |
Reel Outer Dia. |
400mm (15.7in) |
Reel Inner Dia. |
75mm (2.9in) |
Voltage |
AC220V/50Hz, 1phase or Per customer specification |
Power Consumption |
3KW |
Compressed Air Requirement |
0.6 MPa0.36 M3min |
Machine Size |
L1650 x W1140 x H1650; (in):L65.1 X W44.9 X H64.9 |
Machine Weight |
800kg |
