5kw GDE7500T Air-cooled silence type diesel generator set Super Silent Diesel Generator Set kipor
Using super light gasoline engine as the engine system, Low noise, low pollution,The stability of voltage and frequency, compact structural,The superior performance,Overload protection device will automatically shut down, To avoid the damage of the generator, The large capacity fuel tank provides a continuous operation for a long time.
Gasoline generating set can be used for important load without mains supply area facilities to provide power supply, this product is a vehicle-mounted mobile gasoline generating set.
Gasoline generating set can be used for important load without mains supply region set up a complete set of equipment should be new, stable performance, reliable, durable, with a healthy start, signal remote control (including) and the start and stop, and other functions.
Generator Set Parameters
| Generating set | GDE7000ST | ||
| Rated Frequency | Hz | 50 | 60 |
| Prime power | Kva | 4.5 | 5 |
| Standby power | Kva | 5 | 5.5 |
| Rated Voltage | V | 230 | 120/240 |
| Rated Current | A | 19.6 | 41.7/20.8 |
| Rated rotation speed | r/min | 3000 | 3600 |
| Genetator | |||
| Genetator type | GBR5 (190*140mm) | GBR5 (190*140mm) | |
| Pole No | 2 | 2 | |
| Phase number | Single phase | Single phase | |
| Excitation mode | Self-excitation and constant voltage(with AVR) | ||
| Power factor | COSΦ | 1.0 | 1.0 |
| Insulation grade | B | B | |
| Engine | |||
| Engine type | GD186FAE | GD186FAE | |
| Structure type | single cylinder,in-lined,4-stroke,air cooled,direct-injected | ||
| Bore*stroke | mm | 86*72 | 86*72 |
| Engine displacement | L | 0.418 | 0.418 |
| Compression ratio | 19:01 | 19:01 | |
| Rated power | kw | 5.7 | 6.3 |
| Lubrication system | Pressure splashed | ||
| Lube oild brand | Above CD SAE 10W-30,15W-40 | ||
| Lube capacity | L | 1.65 | 1.65 |
| Starter system | 12V Electric system | 12V Electric system | |
| Starting motor capacity | V-KW | 12V 0.8KW | 12V 0.8KW |
| Charging motor capacity | V-A | 12V 5A | 12V 5A |
| Battery capacity | V-Ah | 12V 36Ah | 12V 36Ah |
| Fuel consumption ratio | g/KW.h | 275.1 | 281.5 |
| Fuel type | Engine fuel consumption:0#(summer) -10#(winter) -35# (cold) | ||
| Genset | |||
| Panel type | Common panel | Common panel | |
| Output | Receptacle | 2-Single phase | 2-Single phase |
| DC12V output | Connection pole output | Connection pole output | |
| Nosie level(7m) | dB(A) | 68 | 68 |
| Fuel tank capacity | L | 15 | 15 |
| Overall dimension | mm | 900*565*750 | 900*565*750 |
| Net weigh | kg | 160/165 | 160/165 |
| Packing manner | veneer board+carton box+pallet | ||
| Loading quantity / units: | 20': 72 units | ||
| 40': 154 units | |||
-Waranty
1 year (1000 hours) from get goods.
-Technical support
Technician online contact to support solution for generator maintain.
If any question,pls send email or leave message to Technical Inquiry,they will reply within 24 hours.
-Spare parts support
We support spare parts for our products,within the warranty,most of spare parts is free,but the Express charge
cover by customer.
Also,we support most of Chinese diesel generator parts,if you need any parts and the generator made from
China,contact with our Technician,we will give you reply ASAP.
-Buying
This service begin from 2012 for our customers,most of friend purchase so many products from other supplier,
we support the service for collect goods and export all out,more detail,pls contact with our sales representative.
