Remote Control Clamshell Grab Bucket
Product View
Product Details
Features
1.Long Service Life Orange Peel Hydraulic Grab bucket
2.Low upper head profile allows more vertical rach for higher stacking.
3.Wide openings allow for cleaning out corners of crane body or rail cars.
4.High tensile steel used throughout. Wear resistant steel used on all spade tips.
5.Oversized, hardened cylinder and pivot pins with bushings.
6.Feed lines are directed upward in combination with a hose protection shield.
7.High pressure cylinders and good orange peel shape
8.Bolt-on cylinder shrouds for maximum protectionand ease of maintenance.
9.Easily accessible, yet well protected grease zerkes.
Technical Specification
Type |
Volume(m3) |
Dead Weight (kg) |
Density (t/m3) |
Pulley Diameter (mm) |
Stroke (mm) |
Height (mm) |
SWL(T) |
EL10.0-5000 |
5 |
4900 |
1 |
400 |
3120 |
7.6 |
10 |
EL10.0-2500/5000 |
3.0-5.0 |
5000 |
1.0-1.6 |
400 |
3120 |
7.6 |
10 |
EL15.0-8000 |
8 |
6800 |
1 |
520 |
3750 |
8.4 |
15 |
EL15.0-5000/8000 |
5.0-8.0 |
7000 |
1.0-2.0 |
520 |
3750 |
8.4 |
15 |
EL20.0-10000 |
10 |
9000 |
1 |
650 |
4210 |
9.8 |
20 |
EL20.0-6000/10000 |
6.0-10.0 |
9200 |
1.0-1.8 |
650 |
4210 |
9.8 |
20 |
EL25.0-15000 |
15 |
10200 |
1 |
650 |
4620 |
10.5 |
25 |
EL25.0-8000/15000 |
8.0-15.0 |
10500 |
1.0-1.8 |
650 |
4620 |
10.5 |
25 |
EL32.0-18000 |
18 |
13700 |
1 |
810 |
5180 |
12 |
32 |
EL32.0-10000/18000 |
10.0-18.0 |
14000 |
1.0-1.8 |
810 |
5180 |
12 |
32 |
EL40.0-24000 |
24 |
15400 |
1 |
810 |
5180 |
12 |
40 |
EL40.0-13000/24000 |
13.0-24.0 |
15800 |
1.0-1.8 |
810 |
5180 |
12 |
40 |
Other Type Grabs
Grab Buckets
Grabs For Garbage
Timber Grabs
Grabs For Sand And Gravel
Components And Parts
Factory View
Buying Guides
Pre-sale services: We can provide you with project design, process design, suitable purchase program for your equipment.Also design and manufacture products based on your specific needs, to train your technical personnel.
Sale: We will accompany you to complete the equipment inspection, construction plan and assist in the development process in detail.
After Sale Service: We send technicians to the scene to guide the equipment installation, commissioning and training your operating personnel.
Our company is a professional manufacturer who specializes in producing and selling cranes
and components. The factory covers an area of 38000 square meters. As professional engineering machinery accessories supplier, we provide high quality products and excellent services for a variety of dock, subway construction, river cleaned, building dismantlement, municipal engineering and other large projects. Our products are exporting to more than 40 countries and regions.
Certifications
(1).What is the lifting capacity?
(2).What is the lifting height?
(3).What is the power supply in your country?
(4).Is there any other special requirements?
