200l to 1000l (2bbl to 5bb) Commercial Restaurant Beer Brewery Equipment
Shun Long is one of the most professional manufacturers in China. As you know "Made in China" is famous, and we have our own factory in Jinan city, Shandong province, China. Welcome to visit at any time! There you can check our brewery equipment by yourself, also you can enjoy the delight time that with our engineer to talk about the technology...
Brewing is typically divided into 9 steps: milling, malting, mashing, lautering, boiling, fermenting, conditioning, filtering, and filling.
The mashing-lautering-boiling-whirlpool take place in the brewhosue, turn the malt into wort.
In order to provide the one-stop service, we could help you purchase the yeast, hops and other related raw materials for you.
Shunlong Hot Sale Model Specification | |||||||
Brewery | Fermenter | Number of | Beer Output | Whole | Cellar | Power | Beer Fermentation |
100L | 200L | 6 | 100L | 20 m2 | 1.6M | 15KW | 7-12days |
300L | 600L | 6 | 300L | 40 m2 | 2.2M | 25KW | 7-12days |
500L | 1000L | 6 | 500L | 70 m2 | 2.5M | 35KW | 7-12days |
1000L | 2000L | 6 | 1000L | 100 m2 | 3.1M | 40KW | 7-12days |
2000L | 4000L | 6 | 2000L | 140 m2 | 4.0M | 45-50KW | 8-14 days |
Note: 1hl=100liter; 1Gallon=3.7854liter; 1Barrel (BBL) =117Liter;
Brew house unit :
1) Two mashing tanks : Mash tun/Lauter pot and Kettle/Whirlpool tank (Standard Configuration) Combined mashing tanks and three mashing tanks can be chose.
2) Power Controller : Control and show the temperature and time for the tanks.
3) Wort heat exchanger, yeast adding tank and oxygen filling device, hops adding device, etc.
4) Steam condensing device inside of the room (Heating method can be customized)
5) The raw materials for China, pipeline & valves with German standard;
The motors adopts ABB/Siemens brand , it is more convenient for the customer during operation.
1.Inner are of international standards of quality 304 stainless steel material, high-pressure polyurethane foam insulation, the jacket in accordance with customer requirements, can be polished stainless steel, matt, carbon steel, the form of spraying.
2.The application of international standardized fermented beer production technology, a wide range of temperature control application technology, mirror polishing inside the tank, up to ≤0.8u≤0.6um≤0.2um polishing quality standards, fully meet the PLC automatic cleaning and disinfection of the controlled system requirements.
3.Fermentor cooling jacket at the same time meet the needs of the country the world’s technical standards, the provision of Maitreya paneles, arched passages spinulosa Watt Jacket channel heat exchangers and other methods to meet different cooling media and the pressure of the heat exchange technology needs.
Material: stainless steel AISI 304
thickness: 3mm
Inner surface treatment: cold-rolled plates , 2B surface treatment, welds grinded to Ra 0,8µm.
External surface treatment: cold-rolled plates grinded to SBCooling:
Cylinder: 3 cooling-sections
Conical bottom : 1 cooling-section
Working pressure in cooling-sections - 1,5 bar
Insulation: Polyurethane - thickness 150 mm, density 1,09 g/cm³:both cylinder and conical bottom
External-Jacket: Stainless steel plate - thickness 1,5 mm, both cylinder and conical bottom
Working pressure: 1,5 bar in cylindrical-part (filled-up tank, at 20°C)
Shadowless Manway | Thru the Wall Spray Ball | CIP Lines |
Ball Valve for CIP | Pressure Relief/Vaccumm Valve | Rotating Racking Arm with Ball Valve |
Pull Handle Butterfly for Drain | Thermometer | Thermowell |
Sampler Valve | Three-layer with dimple jacket and 60 °Conical Bottom | Solid round Legs |
Pressure Gauge | Insulated Polyurathane Filled | Mirror polished,no rough edges |
Complete beer brewing equipment description:
1)Raw Materials Pretreatment Department;
2)Mashing Treatment Department;
3)Cooling Treatment Department;
4) Fermentation Treatment Department;
5) Filtering Treatment Department;
6) CIP Treatment Department;
7) Beer distribution Department;
8)Electric controlling Department.
We can supply 50L,100L, 200L, 300L, 500L, 1000L ,2000L,3000L,5000L,10000L and so on capacity beer equipment.
Tell me your specifications and I will customize for you acccording to your requirements.
Full set beer brewery:
Home brewery: 50L,100L pilot/home beer brewery
Commercial brewery: 100L, 200L, 300L, 500L, 1000L, 3BBL, 5BBL, 7BBL, 10BBL pub/restaurant, micro brewery plant
Large brewery plant: 1000L, 2000L,3000L,5000L, 10BBL,15BBL, 30BBL brewery plant
Brewhouse:100L~5000L, mash tun, lauter tank, kettle/whirlpoo tank
Fermentation: 100L~10000L conical fermenters, unitanks, conditioning tank
Bright beer tank: 100L~10000L serving tanks, BBTs
Beer selling: beer tower, beer selling tank, stainless steel beer kegs, keg filling, keg washing, bottle filling, bottle washing, capping machine and etc.
Trade Remarks:
Payment: T/T, or through alibaba Trade Assurance
Trade terms: EXW/FOB/CIF/CFR negotiable
Delivery: by ocean to the discharging port, LCL or FCL
Our equipment is well designed by professional designer, and adjustable according to your request. The best material is used to product your machine. The equipment is carefully packed before delivering.
- LCL/FCL(20GP/40GP/40HQ)
- packed with plastic film in fumigation free wooden case or fixed with iron frame
- up to export standard, suitable for delivery
- customer's requirements available
We ensure every order will not live up to the customers' requirement. Every order will be check by the professional skilled engineer before shipping.
We Serve:
- Customized capacity&configurations proposal list
- CAD/3D layout drawings
- Technical drawings of the equipment-Engineer going abroad for installation, debugging and technical training
- Main guarantee for three years, life long service
