12v 24v 48v Solar Charge Controller Automatic Switc 20A Manual Pwm Solar Charge Controller With Quick Charge
US$ 9.5 - 10.5
MOQ: 30 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
HANFONG
Model Number:
ST4-20
Payment & Shipping
Payment Methods:
Port of Shipment:
Guangzhou or Shenzhen port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
12V/24V Automatic Switc 20A Manual Pwm Solar Charge Controller Price With LCD Digital Screen Controller Solar.US$ 9.5 - 10.5MOQ: 30 Pieces -
Pwm Charge Controllers Manual 20A Solar Controller 12v and Solar Charge Controller Price With Fast ChargeUS$ 9.5 - 10.5MOQ: 30 Pieces
-
Charge Controller Solar 12V/24V Automatic Switc 20A Manual Pwm Solar Charge Controller,with Fully Protection and Quick ChargeUS$ 9.5 - 10.5MOQ: 30 Pieces
-
12V/24V Automatic Switc 20A Pwm Solar Charge Controller With Quick Charge, Guangzhou Manufacturer Factory Price for SalesUS$ 9.5 - 10.5MOQ: 30 Pieces
-
12V 24V 20A Pwm Solar Charge Controller for Home Use Off-grid Solar Energy SystemUS$ 9.5 - 10.5MOQ: 30 Pieces
Place of Origin
Guangdong, China
Brand Name
HANFONG
Model Number
ST4-20
Application
Charger Controller
Rated Voltage
Other, 12V/24V Automatic Switch
Maximum Current
20A
Product Description
Packaging & Shipping
Technical Date
| ST Series Specification | ||||||
| Model Parameters |
10A | 20A | 30A | 40A | 50A | 60A |
| Rated voltage | 12V/24V Automatic voltage recognition | |||||
| Max charge current | 10A | 20A | 30A | 40A | 50A | 60A |
| Max discharge current | 10A | 20A | 30A | 40A | 50A | 60A |
| Full charge cut | 16.5V/33V | |||||
| Low voltage cut | 11V/22V | |||||
| Low voltage restore | 12.6V/25.2V | |||||
| Temperature compensation | -3mv/℃/cell | |||||
| Static current | ≤45mA | |||||
| Voltage drop | <200mv | <200mv | <220mv | <240mv | <270mv | <295mv |
| Wire area max | 4mm² | 6mm² | 10mm² | |||
| Weight | 0.32KG | 0.40KG | 0.72KG | |||
| Box Size | L190*W105*H55 mm | L210*W120*H50 mm | L220*W135*H65 mm | |||
| Packing quantity | 40pcs/carton | 30pcs/carton | 24pcs/carton | |||
| Carton size | L535*W390*H220 mm | L455*W380H270 mm | L470*W420H290 mm | |||
| Gross weight | 0.40KG | 0.50KG | 0.85KG | |||
