VVVF 1000kg 2000kg 3000kg 0.5m/selevator Cargo Lift Hydraulic Warehouse Cargo Elevator
US$ 10,000 - 30,000
MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
MINASTAR
Model Number:
cargo lift
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
China Transportation Cargo Elevator Garage Car Elevator Goods LiftUS$ 10,000 - 30,000MOQ: 1 Piece -
China Elevator Manufacturers Cargo Elevator Size of the Freight ElevatorUS$ 10,000 - 30,000MOQ: 1 Piece
-
China Load Goods Elevator Cargo Elevator Freight ElevatorUS$ 10,000 - 30,000MOQ: 1 Piece
-
China 200KG Cargo Elevator Lift Freight Elevator Hydraulic Goods LiftUS$ 10,000 - 30,000MOQ: 1 Piece
-
China Freight Elevator Cargo Load Lift Freight LiftUS$ 10,000 - 30,000MOQ: 1 Piece
Place of Origin
Jiangsu, China
Brand Name
MINASTAR
Model Number
cargo lift
Usage
Other, freight elevator
Drive Type
AC, DC, Hydraulic
Elevator Type
Goods Elevators
Product Description
Specifications
Cargo Elevator/Goods Lift/Freight Elevator
1.Load:1000kg~5000kg
2.Speed:0.5m/s
3,Reliable and Safe
Cargo Elevator, Cargo Lift, Goods Elevator, Goods Lift, Freight Elevator, Freight Lift with Loading Capacity 1000kg,1600kg,2000kg,2500kg,3000kg,4000kg and 5000kg and Rated Speed 0.5m/s
VVVF 1000kg 2000kg 3000kg 0.5m/s elevator for storey house|small cargo lift|hydraulic warehouse cargo lift
Specification
1. Speed:,0.5m/s
2. Load:1000kg / 2000kg / 3000kg / 4000kg / 5000kg
3. Traction Geared / Traction Gearless / Hydraulic
4. with Machine Room / Machine Roomless
Overview
cargo elevator utilizes the advanced microcomputer control technology, through technical mergence, greatly increased cargo elevator’s performance and quality, greatly reduced the incidence of the fault; by using the exchange of two-speed electric drive technology to elevator, its structure becomes more compact, more convenient maintenance.
cargo elevator has bright and spacious, economical and practical car with the optimized design, which offers convenience for transporting goods safely, reliably and stably. The cargo elevator can be used for different purposes and used in different environments, such as in factories, production lines, warehouses, shopping malls, shopping centers, exhibition halls, libraries, and so on. Its huge loading capacity can meet the needs of customers to great extent.
cargo elevator has bright and spacious, economical and practical car with the optimized design, which offers convenience for transporting goods safely, reliably and stably. The cargo elevator can be used for different purposes and used in different environments, such as in factories, production lines, warehouses, shopping malls, shopping centers, exhibition halls, libraries, and so on. Its huge loading capacity can meet the needs of customers to great extent.
| Model |
Load Kg |
Speed m/s |
Car Size (mm) CW×CD×HK |
Opening Size(mm) PL×LH |
Opening Type |
Shaft Size(mm) SW×SD |
Overhead Hight H2 mm |
Pit Depth H1 mm |
|
| MST-C-1000/0.5 | 1000 | 0.5 | 1400×1600×2200 | 1400×2200 | Center opening Four Panels | 2450×2000 | 4200 | 1450 | |
| MST-C-1000/0.5 | 1000 | 0.5 | 1400×1600×2200 | 1400×2200 | Four Panels Opposite Side | 2450×2070 | 4200 | 1450 | |
| MST-C-2000/0.5 | 2000 | 0.5 | 1800×2300×2200 | 1800×2200 | Center opening Four Panels | 3000×2700 | 4200 | 1450 | |
| MST-C-2000/0.5 | 2000 | 0.5 | 1800×2300×2200 | 1800×2200 | Four Panels Opposite Side | 3000×2770 | 4200 | 1450 | |
| MST-C-3000/0.5 | 3000 | 0.5 | 2200×2600×2200 | 2200×2200 | Center opening Four Panels | 3600×3000 | 4200 | 1450 | |
| MST-C-3000/0.5 | 3000 | 0.5 | 2200×2600×2200 | 2200×2200 | Four Panels Opposite Side | 3600×3070 | 4200 | 1450 | |
| MST-C-4000/0.5 | 4000 | 0.5 | 2400×2900×2200 | 2400×2200 | Center opening Four Panels | 3800×3370 | 4200 | 1450 | |
| MST-C-4000/0.5 | 4000 | 0.5 | 2400×2900×2200 | 2400×2200 | Four Panels Opposite Side | 3800×3370 | 4200 | 1450 | |
| MST-C-5000/0.5 | 5000 | 0.5 | 2500×3500×2200 | 2400×2200 | Center opening Four Panels | 4000×4000 | 4200 | 1450 | |
| MST-C-5000/0.5 | 5000 | 0.5 | 2500×3500×2200 | 2400×2200 | Four Panels Opposite Side | 4000×3970 | 4200 | 1450 | |
cargo elevator|car elevator specifications|freight elevator
