China Factory Price Solar Charge Controller 30A 12V / 24V / 48V

China Factory Price Solar Charge Controller 30A 12V / 24V / 48V photo-1
China Factory Price Solar Charge Controller 30A 12V / 24V / 48V photo-2
China Factory Price Solar Charge Controller 30A 12V / 24V / 48V photo-3
China Factory Price Solar Charge Controller 30A 12V / 24V / 48V photo-4
China Factory Price Solar Charge Controller 30A 12V / 24V / 48V photo-5
China Factory Price Solar Charge Controller 30A 12V / 24V / 48V photo-6
Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
Holley / Hisolar
Model Number:
MPPT-30AD
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Zhejiang, China
Brand Name Holley / Hisolar
Model Number MPPT-30AD
Application Collector Controller
Rated Voltage Other, 12V/24V/48V
Maximum Current 30A
Product Description

china factory price solar charge controller 30A 12V / 24V / 48V.

Features:
Overcharge protection.
Short circuit protection (automatic restoration).
Easy to install and use.
Save energy and electricity consumption.
Environment friendly, lower-cost.
Suitable for polytype battery.
Thunder protection.
Reverse polarity connection protection.

Detailed Images
Technical data
Model
MPPT-30AD
Rated Voltage
12V/24V/48V
Max Load current
30A
Input voltage range
12V~40V/24V~80V/48V~110V
Length ≤1m Charge loop drop
<0.25V
Length ≤1m Discharge loop drop
<0.05V
Over voltage protection
17V/34V/68V
Full charge cut
13.7V/27.4V/54.8V
Low voltage cut
10.5V~11V/21V~22V/42V~43V
Temperature compensation
-3mv/℃/cell
No load loss
≤10mA
Max wire area
4mm²
Ambient temperature
-25℃——+55℃
N.W./pcs
0.74kg
Pcs/ctn
20pcs
G.W./ctn
15.5kg
Packing & Delivery
Certifications
Related Products

Blue, Silver, black optional 15A ce solar charge controller 12/24V Temp compensation.

Rated Voltage:12/24V
Maximum Current:15A

Factory Price CAR3K-481 MPPT high quality solar charge controller for 12v / 24v / 48v Battery System.

Rated Voltage:48V
Maximum Current: -

MPPT-30AD Wholesale promotional products china 30A remote power solar charge controller.

Rated Voltage:12V/24V/48V
Maximum Current:30A

Our Company

HOLLEYINTL, is a top-brand enterprise in China, is a professional diversified operating company specializing in international trade and overseas projects. We have been engaged in export and import of utility meters, new energy and natural resource products as well as overseas engineering EPC and investment. Meanwhile, our company is also the inverter,controller manufacturer; PV system integrator and photovoltaic power plant investment operator.

We actively carrying out the internationalization strategy and extending the domestic and overseas markets, have made great progress in the field of new energy and completed a number of photovoltaic system projects in Ethiopia, Uganda, Palestine as well as other countries, and initially formed the core competence both in PV system integration capabilities and customer service network.

As one of our global strategies, we are aiming to be an global excellent integrated expert in new energy field. We specialize in providing design, supply, installation, commissioning, after-sales service and project finance support of overseas new energy projects and our products have been spread all over Africa, Asia and South America.
