Specifications
hydraulic fire fighting disaster rescue equipment and tool#Two hoses with single connector
#Small Size
# light weight
#can
hydraulic fire fighting disaster rescue equipment and tool
A-disaster rescue tools application
Highway, railway accident rescue, air crash and beach relief; Buildings and disaster relief;Moving obatacles ,top objects,create rescue channels and maintain object stable.
B- disaster rescue tools features
1. Two hose with single connector couplers. Shorten the connecting time.
2. Small Size, light weight, can be packed in the backpack.
3. Fast speed, colsing and opening time is short.
C- disaster rescue tools include hydraulic spreader, cutter, combination, ram and pump.
Hydraulic Spreader Specification
Model |
XHS-500/50-B |
Max. Spreading Distance |
≥500mm |
Rated Working Pressure |
70MPa(700.000bar) |
Max. Spreading Force |
50KN(5T) |
Rated Spreading Force |
35KN(3.5T) |
Hauling Distance |
505mm |
Weight |
≤11kg |
Hydraulic Cutter specification
Model |
XHC-350/110-B |
Max. Opening Distance of Blades |
≥110mm |
Rated Working Pressure |
700bar |
Max. Cutting Capacity |
Φ28mm(circle steel) |
Max. Cutting Force |
350KN(35T) |
Weight |
≤9kg |
Hydraulic Combination Specification
Model |
XHSC-35/240-B |
Max. Opening Distance of Blades |
≥240mm |
Rated Working Pressure |
700bar |
Max. Cutting Capacity |
10mm(steel plate); |
Max.Cutting Force |
300KN(30T) |
Max Spreading Force |
35KN(3.5T) |
Weight |
≤9.5kg |
Hydraulic Ram Specification
Model |
XHR-100/360-B |
Rated Working Pressure |
700bar |
Max. Extending Force |
100KN(10T) |
Closed Length |
≤360mm |
Extending Scope |
360-640mm |
Length of Extending Bar Ⅰ |
100mm |
Weight |
≤9kg |
Hydraulic Pump Specification
Model |
XHP-70/0.5-B |
Power |
Honda GX100 Engine |
Pump Type/Output Type |
100KN(10T) |
Rated Rotating Speed |
4850±200rpm |
Rated Pressure(High Pressure) |
70MPa |
Rated Output Flow(High Flow) |
≥0.5L/min |
Rated Output Flow(Low Flow) |
≥2.3L/min |
Driving Power |
1.7kw |
Gasoline Volume |
1L |
Hydraulic Oil Volume |
1.4L |
Weight |
≤14kg |
Thanks for your time, welcome for more information!
