Keychain Rescue Tool

Name: Keychain Rescue Tool
Brand: XUNKAI
SKU: 127867271
Availability: InStock

US$ 1 - 6,000 MOQ: 1 Set

Key Specifications

Place of Origin:

Shandong, China

Brand Name:

XUNKAI

Model Number:

XHSC-32/325-A

Shandong Xunkai Fire Equipment Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao/Jinan/Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Shandong, China

Brand Name XUNKAI

Model Number XHSC-32/325-A

Specifications

keychain rescue tool
1. 420KN cutting force
2.120 spreading force
3.Accelerate valve
4. 14kg

Keychain rescue tool(includes the hydraulic hand pump, hydraulic spreader and cutter, door openner)

A- car resuce tool applications:

#Traffic accident rescue, earthquake disaster relief and accident rescue etc.;

#Suitable for rescue operations maneuverable;

#Unclenching the door and metal structure into deformation;

#Cut metal structure, vehicle parts, pipeline and metal plates.

B-Material of car resuce tool

The knife is made up of heavy grindin, high strength steel alloy manufactured;

C- car resuce tool functions:

Shearing, expansion and pulling functions. The multi-functional pliers can instead as a cutter and a spreader;

D- car resuce tool features:

#Shearing prevent splashing collapse with automatic reset manually controlled steering valves, provides security for the manipulator;

#Manual control valve operation can drive the blade open and close in any fixed position, with self-locking function;

#Time is short when open and close, accelerating the rescue process;

E- car resuce tool specification

Hydraulic spreader and cutter specification

Model	XHSC-32/325-A
Max. Opening Distance of Blades	≥360mm	≥14 in.
Rated Working Pressure	700bar	10150 psi
Max. Cutting Capacity(Q235steel)	15mm(steel plate);Φ28mm(circle steel)	0.6 in.(steel plate); Φ1.1 in.(circle steel)
Max. Cutting Force	325KN(32.5T)	69500 lbs
Max. Spreading Force	100KN(10T)	7050 lbs
Hauling Distance	230mm	9 in.
Rated Hauling Force	55KN	12100 lbs
Weight(working condition)	≤14kg	≤30.8 lbs
Dimension(LWH)	765210170mm	30.18.36.7 in.

Hydraulic door openner

hydraulic hand pump

Model	XHP-70/1.5-A
Rated Output Pressure(High Pressure)	700bar	10150 psi
Rated Output Flow	≥1.5ml/time	0.09 cu.in./min
Pressure of Low-Pressure Output	5-10MPa(50.000-100.000bar)	72.5-145 psi
Low Pressure Flow	≥12ml/time	0.73 cu.in./min
Tank Volume of Hydraulic Oil	≥2.0L/time	121 cu.in./min
Max. Handle Force Needed	≤350N(0.350KN)	≤78.7 lbf
Weight	≤5kg	≤11 lbs
Dimension(LWH)	570140170mm	22.45.56.7 in.
