Forcible Entry Tools/break in Tools

Name: Forcible Entry Tools/break in Tools
Brand: XUNKAI
SKU: 127867261
Availability: InStock

US$ 1 - 6,000 MOQ: 1 Set

Key Specifications

Place of Origin:

Shandong, China

Brand Name:

XUNKAI

Model Number:

XHSC-32/325-A

Shandong Xunkai Fire Equipment Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao/Jinan/Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Shandong, China

Brand Name XUNKAI

Model Number XHSC-32/325-A

Specifications

forcible entry tools/break in tools
1. 420KN cutting force
2.120 spreading force
3.Accelerate valve
4. 14kg

Forcible entry tools/break in tools (includes the hydraulic pump, hydraulic spreader, hydraulic cutter)

A- forcible entry tools/break in tools applications:

#Traffic accident rescue, earthquake disaster relief and accident rescue etc.;

#Suitable for rescue operations maneuverable;

#Unclenching the door and metal structure into deformation;

#Cut metal structure, vehicle parts, pipeline and metal plates.

B-Material of forcible entry tools/break in tools

The knife is made up of heavy grindin, high strength steel alloy manufactured;

C- forcible entry tools/break in tools functions:

Shearing, expansion and pulling functions. The multi-functional pliers can instead as a cutter and a spreader;

D- forcible entry tools/break in tools features:

#Shearing prevent splashing collapse with automatic reset manually controlled steering valves, provides security for the manipulator;

#Manual control valve operation can drive the blade open and close in any fixed position, with self-locking function;

#Time is short when open and close, accelerating the rescue process;

E- forcible entry tools/break in tools specification

Hydraulic spreader specification

Hydraulic cutter

Model	XHC-420/150-A
Max. Opening Distance of Blades	≥150mm	≥5.9 in.
Rated Working Pressure	700bar	10150 psi
Max. Cutting Capacity(Q235 steel)	15mm(steel plate);Φ28mm(circle steel)	0.6 in.(steel plate); Φ1.1 in.(circle steel)
Max. Cutting Force	420KN(42T)	92594 lbs
Opening Time without Load (Powered by motor pump)	≤25s	≤25s
Closing Time without Load (Powered by motor pump)	≤30s	≤30s
Weight(working condition)	≤13kg	≤28.7 lbs
Dimension(LWH)	690210170mm	27.28.36.7 in.

Hydraulic Pump

Model	XHP-70/0.66-A
Power	Honda GX100 Engine	Honda GX100 Engine
Pump Type/Output Type	Double-acting Piston/Double-output Pump	Double-acting Piston/Double-output Pump
Rated Rotating Speed	3200±200rpm	3200±200rpm
Rated Pressure(High Pressure)	70MPa*2	10150 psi *2
Rated Output Flow(High Flow)	≥0.66L/min*2	40.2 cu.in./min*2
Rated Output Flow(Low Flow)	≥2.0L/min*2	122cu.in./min*2
Driving Power	1.7kw	2.3 HP
Gasoline Volume	1L	61 cu.in.
Hydraulic Oil Volume	3L	183 cu.in.
Applicative Temperature	-30°C ~ 55°C(86°F~131°F)	-30°C ~ 55°C(86°F~131°F)
Weight	≤27kg	59.5 lbs
Dimension(LWH)	390340460mm	15.313.418.1 in.
