Home > Electrical & Electronics > Optical Fiber, Cable & Wire > Electric Wire & Cable > Bare Conductor Acsr Bare Conductor
Bare Conductor Acsr Bare Conductor
US$ 0.2 - 3.6
MOQ: 100 Meters
Key Specifications
Get Latest Price
Place of Origin:
Henan, China
Brand Name:
Sanhe
Model Number:
acsr
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
A.A.C.&A.C.S.R Bare Conductors Cable Acsr ConductorUS$ 0.2 - 3.6MOQ: 100 Meters -
Aluminum Conductor AAC Cable/AAAC ACSR AAC Overhead Cable/All Aluminum AAC Conductor,Electrical Wire PricesUS$ 0.2 - 3.6MOQ: 100 Meters
-
ACSR Dog Conductor Price /477mcm ACSR Conductor Cable/ACSRUS$ 0.2 - 15MOQ: 5000 Meters
-
Aluminum Wire for ACSR Conductor Standard ASTM B232, DIN 48204, BS 215US$ 0.2 - 15MOQ: 5000 Meters
-
ACSR CONDUCTORS 150 MM SQ WOLFUS$ 0.2 - 15MOQ: 5000 Meters
Place of Origin
Henan, China
Brand Name
Sanhe
Model Number
acsr
Insulation Material
Other, Non
Type
High Voltage
Application
Overhead
Conductor Material
Aluminum
Jacket
Other, Non
| BS-215-2-70 ACSR | ||||||||||
| Code nane | Nominal Area | Stranding &Wire Diameter | Approximate overall diameter | Section Area | Approximate weight | |||||
| Aluminum | Steel | Aluminum | Steel | Total | ||||||
| mm² | No. | mm | No. | mm | mm | mm² | mm² | mm² | Kg/km | |
| Rabbit | 50 | 6 | 3.35 | 1 | 3.35 | 10.05 | 52.9 | 8.8 | 61.7 | 214.1 |
| Dog | 100 | 6 | 4.72 | 7 | 1.57 | 14.15 | 105 | 13.6 | 118.5 | 394.7 |
| Gopher | 25 | 6 | 2.36 | 0 | 2.36 | 7.08 | 26.2 | 0 | 26.2 | 72.1 |
| Weasel | 30 | 6 | 2.59 | 1 | 2.59 | 7.77 | 31.6 | 5.3 | 36.9 | 128 |
| Ferret | 40 | 6 | 3 | 1 | 3 | 9 | 42.4 | 7.1 | 49.5 | 171.7 |
| Horse | 70 | 12 | 2.79 | 7 | 2.79 | 13.95 | 73.4 | 42.8 | 116.2 | 538.1 |
| Wolf | 150 | 30 | 2.59 | 7 | 2.59 | 18.13 | 158.1 | 36.9 | 194.9 | 725.9 |
| Dingo | 150 | 18 | 3.35 | 1 | 3.35 | 16.75 | 158.7 | 8.8 | 167.5 | 507.4 |
| Lynx | 175 | 30 | 2.79 | 7 | 2.79 | 19.53 | 183.4 | 42.8 | 226.2 | 842.4 |
| Caracal | 175 | 18 | 3.61 | 1 | 3.61 | 18.05 | 184.2 | 10.2 | 194.5 | 589.2 |
