Overview:
APT-WR300 is ar9341 chipset based Wireless N Router combined wired / wireless routers functions, complies IEEE 802.11n standard with wireless transmission speed up to 300Mbps,1*WAN port ,1*10/100Mbps LAN port,1 Console port to achieve the most effective data transmission.
-Support PPPoE,Dynamic IP,and static IP broadband functions
-Support UPnP,DDNS,static routing,VPN Pass-through
-Support virtual server,special application and DMZ host
-Support SSID broadcast control and MAC access control list
-Supports 64/128/152-bit WEP, complies 128 bit WPA (TKIP/AES)
-Support MIC,IV Expansion,shared Key Authentication,IEEE 802.1X
-Built-in firewall features IP,MAC,URL filtering
-Built-in DHCP server with automatic dynamic IP address distribution
-User interface supports free WEB software update
Specifications:
| Hardware | |
| Model Number | APT-WR300 |
| Chipset | AR9341/535MHZ |
| Flash | 8MB(max 16MB) |
| SDRAM | 64MB |
| Antenna |
2*5dBi detachable antennas 802.11b=18dBm/802.11g=16dBm/802.11n=14dBm |
| Interface | 1*WAN,1*LAN,1*USB,1*Console |
| Button | Reset |
| LED | SYS/USB/WLAN/WAN/Port3/Port2/Port1/Port0 |
| Power Supply | DC 12V/1A |
| Software | |
| System | DD-wrt,openWrt |
| Work Mode | AP;Router;repeater |
| WAN Type | DHCP,Static IP,PPPoE,L2TP,PPTP,Dual Access,WISP |
| Port Forwarding | Virtual Servers,Port Triggering,UPnP,DMZ,FTP Private Port |
| QoS | WMM, Bandwidth Control for gaming mode |
| Access Control | IP/MAC/Domain Filtering |
| VPN Pass-through | PPTP,L2TP,IPSec |
| Wireless | |
| Standard | IEEE802.11b/g/n |
| Frequency Range | 2.4-2.4835GHz |
| Signal Rate | Up to 300Mbps |
| Data Transfer Rate | 11n: Up to 300Mbps (dynamic) |
| 11g: Up to 54Mbps (dynamic) | |
| 11b: Up to 11Mbps (dynamic) | |
| Security | WEP,WPS,MAC filter,WPA-PSK,PWA2-PSK,WPA/WPA-PSK |
| Coverage | 100M(diameter) |
| User | 30-40 |
| Other | |
| Dimention(mm) | 200*125*30mm |
| Weight(g) | 320g |
| Operating Temperature | 35~+75ºC (-31~+167°F) |
| Storage Temperature | -40~+85°C (-40~+85°F) |
| Operating Humidity | 95% (Non-condensing) |
Shipping by EMS/FedEx/DHL/UPS/TNT/Air/Sea etc.
20pcs/ctn,kraft paper box or OEM package.
•All products have been checked and packaged in good condition before dispatching.
•All products have 2 years warranty.
•Provide OEM/ODM service.
Shenzhen APT Communication Technology Co.,Ltd.is located in Shenzhen China,establishedsince 2012.
We provide OEM/ODM manufacturing service for network equippment hardwares like Ethernet.
switch/POE switch/Splitter/Injector,WIFI access point/router/bridge/CPE,media
converter/Fiber switch etc.
We have experienced engineer team to design excellent performance hardwares at reasonable.
price and fast lead time.Our engineers used to develop H3C products.
