Vibrating Tumbler Swinging Screen

We promise 12 months warranty and return cargos if quality problem

XC1600 swing screen actual photos

Overview of XC1000 swing sieve
Xianchen mechanical swing sieve is designed to meet the high output and high precision screening of manufacturers and special design of an efficient screening machine. The most simple screening is a binocular fixation and both hands screening. Swinging sieving machine is the simulation of this movement. At present, the most effective simulated artificial sieving movement effective principle (screening accuracy, efficiency, Screen life are 5-10 times than conventional round sieve). It meets all the fine and ultrafine particulate materials, especially for hard to process materials.

Swinging sieve structure principle

• The basic rotary motion is similar to that of the artificial sieve, and the eccentricity ratio is adjustable from 25 to 40mm, and the low speed V type belt drive can be adjusted from 120 to 360rpm.
• The residence time of each product can be adjusted by the radial direction and the tangential angle of the swinging screen.
• Therefore, established the level and throwing three-dimensional tumbling motion. from the center to the outer edge in the sieve surface is uniformly dispersed, to in a spiral motion to the axial propagation. Thus fine particles complete the whole screening process.
• Horizontal and vertical acceleration with the movement of the material increased, and close to the aperture size of particles subsequently successfully separated ;Larger particles were transported to the exit, the outlet is controlled by an adjustable guide device, which is another factor that controls the retention time of the material.
• The process is repeated among each layer of screen.

Dimensions

 XC1600 swing screen details

Swinging sieve characteristics

Up to 5 times the output per unit area; Accurate to 6 level separation, screening efficiency as high as 90%-99%; The use of silicone rubber ball, ultrasonic high effect clear net device system, the mesh not blocked. Closed dust removal, operation safety; The acceleration is 4.5 times lower than that of the vibrating screen, the life of the screening part is improved, and the maintenance is reduced; Noise less than 70 dB. Optimal equilibrium, low dynamic load of foundation.

XC1600 swing sieve cleaning net way

Bouncing ball cleaning: meet the food grade rubber, silica-gel sphere beat in the punching plate screen, hit the metal net, reduce clogging of the mesh. This system is simple and easy to use, easy to maintain, and is suitable for most granular materials.

Rotary brush cleaning: The rotary drum brush is driven by a reduction gear arranged on the base plate, rotating brush under the sieve net, cleaning materials, suitable for screening spherical, crystallization and brittle material.

Ultrasonic cleaning: high frequency ultrasound is transmitted to the screen net, both to clean the screen, and significantly improve the production ability. Applicable to the most sophisticated, high yield, difficult screening material.

Simulated artificial high efficiency screening

Application

chemical, food and spices, plastics, mining, medicine, wood and plywood, metallurgy, rubber, feed, fertilizer, sugar, salt, and recycling industries.

Exhibition & Customers

Packaging & Shipping


Packaging & Delivery

 Packaging Details: Can be packed according to the size of the machine.Our standard exporting packing is Fumigation-free wooden case,and 1 set/case. If you have special requipment,please just inform us.
Delivery Detail : 22days after receipt of your require


FQA

       1. How to choose the machine?

a: Customers who are familiar with technical performance and parameters can directly order.
Note: You had better send us the pictures you have ever used.
b: Customers who need us to choose the models, please follow the information, tell us:
• Name and feature of the raw material?
• Aim of using: get rid of impurity, filtration, grading
• Handling capacity: kg /h, L/h
• The raw material size: (mesh or mm)
• How many final materials you want, or how many layer you need?
Note: You had better send us the relevant pictures about the details.
2.How many kinds of material are supported?
• All stainless steel (304, 316L)
• All carbon steel Q235
• Contact part Stainless steel
3.Is it special requirement available?
Packaging & Delivery
Wooden case or as your payment
20 days after receipt of your require

This machine also could be customized by clients' specific production line requirement.
