High Quality and Low Cost Food Grade Round Swing Vibrating Screen for Flour

High Quality and Low Cost Food Grade Round Swing Vibrating Screen for Flour thumbnail-1
High Quality and Low Cost Food Grade Round Swing Vibrating Screen for Flour thumbnail-2
High Quality and Low Cost Food Grade Round Swing Vibrating Screen for Flour thumbnail-3
High Quality and Low Cost Food Grade Round Swing Vibrating Screen for Flour thumbnail-4
High Quality and Low Cost Food Grade Round Swing Vibrating Screen for Flour thumbnail-5
High Quality and Low Cost Food Grade Round Swing Vibrating Screen for Flour thumbnail-6
High Quality and Low Cost Food Grade Round Swing Vibrating Screen for Flour photo-1
High Quality and Low Cost Food Grade Round Swing Vibrating Screen for Flour photo-2
High Quality and Low Cost Food Grade Round Swing Vibrating Screen for Flour photo-3
High Quality and Low Cost Food Grade Round Swing Vibrating Screen for Flour photo-4
High Quality and Low Cost Food Grade Round Swing Vibrating Screen for Flour photo-5
High Quality and Low Cost Food Grade Round Swing Vibrating Screen for Flour photo-6
US$ 2,000 - 7,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Henan, China
Brand Name:
Xianchen
Model Number:
XC1000-1S
Contact Supplier Request Quote Chat Now
Xinxiang Xianchen Vibration Machinery Co., Ltd.
Gold Verified Supplier
6Yrs
Payment & Shipping
Payment Methods:
Port of Shipment:
Shangahi Qingdao Dalian
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Henan, China
Brand Name Xianchen
Model Number XC1000-1S
Type Grain Processing Equipment
After-sales Service Provided Engineers available to service machinery overseas

High quality and Low cost Food Grade round Swing vibrating screen for flour





High quality and Low cost Food Grade round Swing vibrating screen for flourHigh quality and Low cost Food Grade round Swing vibrating screen for flour



High quality and Low cost Food Grade round Swing vibrating screen for flourHigh quality and Low cost Food Grade round Swing vibrating screen for flour

Product Description



Working principle -- Swing Sieve





Basic rotary motion is similar to hand screening .The eccentricity is adjustable from 25 to 40mm, low-speed V-belt drive is adjustable from 120 to 360rpm.Each product' dwell time can be adjusted in a radial and tangential angle ,towards the drive axis. Therefore, establishing the horizontal and throwing three-dimensional rolling movement, materials are evenly dispersed on the entire sieve surface from the center to the outer edge, and thus spread towards the axis by spiral movement. Small particles are then finished in the whole sieving process. The horizontal and vertical acceleration are increased with the movement of the particles. Then the particles which are close to mesh size will be successfully separated; The larger particles are transported to the exit, the flow can be controlled by a regulated oriented device at the exit, the oriented device is another factor which controls the dwell time of the materials.

High quality and Low cost Food Grade round Swing vibrating screen for flourHigh quality and Low cost Food Grade round Swing vibrating screen for flour

Structure Details -- Swing Sieve





High quality and Low cost Food Grade round Swing vibrating screen for flour

High quality and Low cost Food Grade round Swing vibrating screen for flourHigh quality and Low cost Food Grade round Swing vibrating screen for flour



Advantages -- Swing Sieve



1. Up to 5 times the output per unit area;

2. Accurate to 6 level separation, screening efficiency as high as 90%-99%;

3. The use of silicone rubber ball, ultrasonic high effect clear net device system, the mesh not blocked. Closed dust removal, operation safety;

4. The acceleration is 4.5 times lower than that of the vibrating screen, the life of the screening part is improved, and the maintenance is reduced;

5. Noise less than 70 dB. Optimal equilibrium, low dynamic load of foundation.



Technical Parameters -- Swing Sieve



Model

Layer

Screen specifications

Screen box

motor

A

B

C

D

E

F

G

H

height

each floor

Travel

power

Speed




(mm)

(kw)

(rpm)

(mm)

(kg)

XC1000

1S

730

20-80

1.5

960

900

1550

1270

650

150

1000

200

140

490

2S

1410

535

3S

1550

580

XC1200

1S

1060

20-80

2.2

1000

1800

1320

700

150

1200

200

140

700

2S

1460

770

3S

1600

840

XC1600

1S

2000

30-90

3

1450

2250

1500

830

200

1600

300

160

980

2S

1660

1060

3S

1820

1140

XC2000

1S

3000

40-90

4

1600

2700

1630

950

250

2000

300

160

950

2S

1790

1140

3S

1950

1230

XC2600

1S

5150

40-100

5.5

1950

3300

1870

1080

250

2600

400

180

1900

2S

2050

2000

3S

2230

2100



Application -- Swing Sieve



High quality and Low cost Food Grade round Swing vibrating screen for flour



Chemical industry: resin, coatings, industrial medicine, cosmetics, paint, Chinese medicine powder and so on.

The food industry: sugar, starch, salt, Rice noodles, milk powder, Soybean Milk, egg powder, soy sauce, juice and so on.

The metal, mining and Metallurgy: aluminum powder, lead powder, copper powder ,mineral,alloy powder, electrode powder, manganese dioxide, electrolytic copper powder, electromagnetic materials,abrasive powder, refractory material, kaolin, lime, alumina, ground limestone,quartz sand and so on

Company Information

 High quality and Low cost Food Grade round Swing vibrating screen for flour



  Xinxiang Xianchen Vibration Machinery Co,. Ltd ,which is established in the year of 2009, located in China biggest machinery manufacture base Henan province, is a professional vibration machinery manufactures which specializes in the production of sieving equipments, conveying equipments, crushing equipments and feeding equipments as well as relevant parts. we committed to solve all kinds of sieving problem.

  Our tenet: "market oriented, technology based, quality of survival, innovation and development ".We have passed ISO9001:2008 certification. Under the guide of international quality management system, our products have won not only good reputation in china but also applauses by foreign clients like  United States, Germany, Turkey, Indonesia and so on.



Meching Process



High quality and Low cost Food Grade round Swing vibrating screen for flour



Exhibition & Customers



High quality and Low cost Food Grade round Swing vibrating screen for flour



Certificate & Honor



High quality and Low cost Food Grade round Swing vibrating screen for flour



Packaging & Shipping



Wooden case or as your payment
15days after receipt of your require



High quality and Low cost Food Grade round Swing vibrating screen for flour





Our Services



 1. Pre-sale service:
   a. In order to let each customer know better about the performance and requirements, we provide these services
   b. To send each potential customer the detailed production information and company profile
   c. According the user’s different needs, we work to recommend and guide for them
   d. To help them select the appropriate equipment
2. Service during sale:
   a. Do good communication with customers, so that each part can exchange the information.
   b. Deliver on time as per the contract clause.
3. After-sale service:
   a. To track the customer’s feedback after receiving the equipment
   b. Any product quality we receive, the technical personnel will guide to solve the problem
   c. All the products have three guarantees
   d. Provide technical exchanges
   e. Do well about the work of maintenance and service


FAQ



1. How to choose the machine?

a: Customers who are familiar with technical performance and parameters can directly order.
Note: You had better send us the pictures you have ever used.
b: Customers who need us to choose the models, please follow the information, tell us:

• Name and feature of the raw material?
• Aim of using: get rid of impurity, filtration, grading
• Handling capacity: kg /h, L/h
• The raw material size: (mesh or mm)
• How many final materials you want, or how many layer you need?
Note: You had better send us the relevant pictures about the details.

2.How many kinds of material are supported?

• All stainless steel (304, 316L)
• All carbon steel Q235
• Contact part Stainless steel
3.Is it special requirement available?
This machine also could be customized by clients' specific production line requirement.



Welcome your inquiry !!!
