Hot sale linear vibrating screen machine for plastic pellets seperating
Linear sieve working principle :
Linear vibrating screen dual vibration motor, vibration motor when the two do synchronized reverse rotation, the centrifugal force generated by its eccentric block cancel each other in parallel to the motor axis direction, In the fold is perpendicular to the direction of the motor shaft for a resultant force, so the trajectories of sieve machine for a straight line. Its two motor shaft relative screen surface has a dip at the joint effect of the exciting force and material self gravity . The material on the sieve was thrown up by leaps and bounds ahead for linear motion, so as to achieve the purpose of the material screening and grading. With low energy consumption, high efficiency, simple structure, easy maintenance, fully enclosed structure no dust features.2to400 mesh sieve mesh, screening out nine different particle size of materials.
Introduction to work:
Technical parameters:
Model |
XC520 |
XC525 |
XC530 |
XC1020 |
XC1025 |
XC1030 |
XC1225 |
|||
Nominal Size |
500×2000 |
500×2500 |
500×3000 |
1000×2000 |
1000×2500 |
1000×3000 |
1200×2500 |
|||
Particle Size(mm) |
0.074-60 |
0.074-60 |
0.074-60 |
0.074-60 |
0.074-60 |
0.074-60 |
0.074-60 |
|||
Shake frequency |
960 |
|||||||||
Screen slope |
1°-7° |
1°-7° |
1°-7° |
1°-7° |
1°-7° |
1°-7° |
1°-7° |
|||
Swing |
1-4.5 |
1-4.5 |
1-4.5 |
1-4.5 |
1-4.5 |
1-4.5 |
1-4.5 |
|||
Layer |
1-6 |
1-6 |
1-6 |
1-6 |
1-6 |
1-6 |
1-6 |
|||
Power |
2(0.37-0.75) |
2(0.37-0.75) |
2(0.37-0.75) |
2(0.37-1.1) |
2(1.1-1.5) |
2(0.75-1.5) |
2(0.75-1.5) |
|||
Workshop process:
Packaging & Shipping:
Our services:
Experienced technicians guidance is available on the phone, and on the internet. As per different customers' demand, XianChen develops the best match design, professional technical guide, and premium after sale -service for you,aimming to optimitze you investment,enhance your project efficiency, and increase your profit.
FAQ:
1. What’s the materials to process?
2. What’s the feature of the materials? Like density, moisture degree,input particle size and output particle size.
3. How many layers do you need ? And what’s the screen mesh about each layer?
4. What’s your capacity per hour?
5. What's material for the machine?Stainless steel or contact part stainless steel or carbon steel??
6. Other special requirement.
Have any needs, please contact us!
