Home > Electrical & Electronics > Optical Fiber, Cable & Wire > Electric Wire & Cable > PVC Insulation Power Cable
PVC Insulation Power Cable
US$ 1 - 30
MOQ: 100 Meters
Key Specifications
Get Latest Price
Place of Origin:
China
Brand Name:
New Huiyuan
Model Number:
PVC
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Underground Armoured Xlpe 11kv Power Cable China Manufacturer PriceUS$ 10 - 100MOQ: 100 Meters -
2016 New Power Cable 240 sq mm Factory Price Made in ChinaUS$ 1 - 50MOQ: 500 Meters
-
Underground Transmission Line 132kV High Voltage XLPE Power CablesUS$ 20 - 200MOQ: 500 Meters
-
35kv or Below XLPE Insulated Power CableUS$ 20 - 50MOQ: 500 Meters
-
11kv Power Cable 1x120mm2 3x240mm2US$ 10 - 100MOQ: 100 Meters
Place of Origin
China
Brand Name
New Huiyuan
Model Number
PVC
Insulation Material
PVC
Type
Medium Voltage
Application
Construction
Conductor Material
Copper
Jacket
PVC
Product Description:
0.6/1KV or Below PVC Insulated and Sheathed Power Cable
This product is used for the Power Transmission of Electrical Circuit of rated AC Voltage 0.6/1KV.
Production Standard:
China Standard: GB/T12706.1
IEC Standard: IEC60502.
Feature:
- Cable Conductor Long time working Temperature should be less than 70ºC
- During Short Circuit (Max Time should be less than 5 Seconds), Max Temperature of Cable Conductor is less than 160ºC
- Surrounding Environmental Temperature during Cable Laying should not be less than 0ºC.
Basic Model
| Model | Name | Application | |
| Copper | Al | ||
| VV | VLV | PVC Insulated PVC sheathed Power Cable | It is used inside Room, Tunnel, Cable Groove or Pipes. Cable cannot be hit by External Mechanical Force. |
| VV22 | VLV22 | PVC Insulated PVC sheathed Steel Strip Armored Power Cable | This is laid underground, it Can bear some External Mechanical Force, But it cannot bear large Pulls. |
Note:
- "Flame Retardant" "Fire Resistant" Cable can also be offer, For "Flame Retardant" Type, "ZR-" should be added before the previous model code, For "Fire Resistant" Cable, "ZH-" Should be added.
- VV32 Type and VLV32 Type Steel Wire Armored Power Cable can also be offered. Single Core Steel Wire Armored Power should be Magnetically isolated
Products Scope:
| Model | Core | Cross Section MM2 | |
| Copper | Al | ||
| VV VV22 | VLV VLV22 | 1 | 1.5~500 2.5~500 10~500 |
| VV VV22 | VLV VLV22 | 2 | 1.5~185 2.5~185 4~185 |
| VV VV22 | VLV VLV22 | 3 | 1.5~300 2.5~300 4~300 |
| VV VV22 | VLV VLV22 | 4 | 2.5~300 2.5~300 4~300 |
| VV VV22 | VLV VLV22 | 3+1 | 4~300 4~300 |
Note:
- 5 Cores Cable can also be offered
- Armor Layer of Single Core Armored Cable for AC System should be wrapped with Non-Magnetic Metal Strips.
Technical Parameters:
1): Max DC Resistance of the Conductor in 20ºC should meet Requirement of 2nd Type Conductor in the Standard of GB/T3956
2): A.C. Voltage Test: Single Core Non-Shielding Core should be immersed into water for 1 hour and impose Testing Voltage of 3.5KV/5 Min between the Conductor and Water. For Multi-Core Cable, Please input Testing Voltage of 3.5KV/5 Min between each core and all the rest cores, after testing, Insulation layer should be Breakdown Free.
