Help Center100w Monocrystalline Solar Cells for Sale With TUV CE IEC CEC ISO
Related Products
-
2012 High Efficiency Low Price 260w Solar Panel With TUV,CE,ISO,CECUS$ 0.72 - 1.01MOQ: 2 Pieces -
Low Price 235Wp Solar PV PanelsUS$ 0.55 - 0.89MOQ: 10 Pieces
-
Poly 225w-240w PV Solar Panel With TUV,CE,ISO,CECUS$ 0.53 - 0.7MOQ: 10 Pieces
-
Poly 225w-240w Solar for Home Use With TUV,CE,ISO,CECUS$ 0.53 - 0.7MOQ: 10 Pieces
-
Grade A Cell Mono 5-40W Solar Panel With CE TUVUS$ 0.62 - 0.7MOQ: 25 Pieces
Specifications
1.100% TUV standard flash test2.high efficiency solar panel 10W-320W
3.Low price with quality insurance
4.TUV,CE, IEC, CEC
100% TUV standard low price mono solar panel 85Wp-100Wp, Trust pass TUV, CEC, IEC, CE, ISO certificate.
1.What is 100% TUV standard flash test?
Flash test machine with TUV standard reference solar panel,all Propsolar Panel is tested under 100% TUV standard flash test or standard higher than TUV standard
In the market,not all solar panel is real tested with TUV standard,Flash machine reference panel is not TUV standard,so the power is 2%-3% less than TUV standard
2.Descprition:
HSPV--85Wp-100Wp-125-36M Series solar panel is connected in series by 36 pieces of 156mm×156mm mono Crystalline silicon cells. Includes 85W, 90W, 95W, 100W
3.Characteristics
1)Manufactured according to international quality and Environment Management
System (ISO9001, ISO14001)
2)High efficiency crystalline silicon solar cells
3)High transmission Iow iron tempered glass, strong mechanical resistance
4)Anti-ageing EVA and excellent anti-climate back sheet
5)Anodized aluminum frame improves load resistance capabilities for heavy wind loads.
6)Standard waterproof junction box
7)High endurance to different weather
8)Good and friendly package with less transportation and storage space.
3.Warranty
1)10 years limited manufacturing warranty
2)12 years for 90% of warranted minimum power
3)25 years for 80% of warranted minimum power
4.Electric Characteristics
| Module Type | HSPV--85Wp-125-36M | HSPV--90Wp-125-36M | HSPV--95Wp-125-36M | HSPV--100Wp-125-36M |
| Maximum power at STC (Pmax) | 85w | 90w | 95w | 100w |
| Maximum power voltage (Vmp) | 18.0 | 18.0 | 18.1 | 18.2 |
| Maximum power current (Imp) | 4.72 | 5.00 | 5.24 | 5.49 |
| Open circuit voltage (Voc) | 21.6 | 22.0 | 22.2 | 22.4 |
| Short circuit current (Isc) | 5.30 | 5.56 | 5.68 | 5.85 |
| Nominal Operating Cell Temperature | 45 ± 2°C | |||
| Temperature coefficients of Isc | +0.049% /°C | |||
| Temperature coefficients of Voc | -0.340% /°C | |||
| Temperature coefficients of Pmax | -0.430% /°C | |||
| Standard Test Conditions (STC) | Irradiance 1000W/m2, Module temperature 25°C, Air Mass (AM)=1.5 | |||
| Power Production Tolerance | ± 3% | |||
Hilight Solar have own solar panel factory and specialized in manufacture mono & poly solar panel 10Wp-320Wp for years, we are Gold Supplier and Trustpass Supplier in the . Gained TUV, CEC, IEC, CE, ISO certificate.
Our Workshop
Hilight Solar , Power Your Future ; Hilight Solar , Your Best Choice
"Hilight Solar" PanelWidely Used All Over The World
1. Large or small on-grid or off-grid solar panel systems.
2. Commercial and industrial building roof-top solar panel systems
3. Residential roof-top solar panel systems
4. Commercial or industrial ground mounting solar panel systems
5. Other industrial or commercial applications
Company Profile
Our Packing
Our Products
Our Certificates
