Specifications
Solar Water Pump with competitive price1. Flow:5-3 stere& head: 223-134m
2.Easy installation
3.Good waterproof protect
Specifications
Solar Water Pump with competitive price
1. Flow:5-3 stere& head: 223-134m
2.Easy installation
3.Good waterproof protection
Solar water pump flow rate: 1.5-3m³& head: 223-134m , 220V, 2.2 kw
Solar Water Pump with competitive price
1. Flow: 1.5-3m³& head: 223-134m, solar water pump
2.Easy installation
3.Good waterproof protection
Description
Our solar water pump adopts cutting-edge technology, which applies for domestic house supply, agriculture and industrial use. What's more, we can also provide you with customer-made water pump system, so that you can have the best-ever service. Our pumps vary in flow rate and head/lift (we shall recommend to you the best solution based on your requirement). The flow rate and head/lift are 1.5-3m³& 123-134m .Length of the pump is 1190mm and connection diameter is 32mm /1.25 inch .Should you have any questions, please feel free to contact us, we shall answer all your questions, you can reach us at any time.
I. Application:
1. Domestic water supply
2. Central water supply
3. Industrial water pumping
4. Gardening water pumping
5. Agricultural irrigation
6. Desertification control
II. Advantage
Applications Innovation: The DC pump brushless motor has increased its efficiency up to 25% in comparison with traditional small asynchronous motor.
Technology Innovation(Patent):Stator and rotor are sealed by environment-friendly casting resin.The motor's insulation resistance is more than 10 years long. it greatly increased the safety and reliability of the submersible motor.
Structure Novelty: Stator and rotor processed by casting resin technology as well as the water lubricated bearing make the submersible pump more environment friendly,easier to install and more reliable.
III. Model of pump
| NO. | Type of Pump | Power of Pump (KW) |
MPPT controller (V) |
Solar panel(KWp) | Flow rate (m3/h) /head (m) (optimal use scope) |
Outlet diameter (mm/inch) |
Pump length (mm) |
||
| 1 | 4SP2-9A | 0.37 | 48 | 0.72(4pcs 180Wp) | 1.5 /40 | 2 /38 | 3 /25 | 32 /1.25 | 371 |
| 2 | 4SP2-13A | 0.55 | 110 | 1.175(5pcs 235Wp) | 1.5 /60 | 2 /56 | 3 /36 | 455 | |
| 3 | 4SP2-18A | 0.75 | 110 | 1.44(8pcs 180Wp) | 1.5 /85 | 2 /77 | 3 /50 | 560 | |
| 4 | 4SP2-23A | 1.1 | 220 | 2.115(9pcs 235Wp) | 1.5 /107 | 2 /98 | 3 /66 | 665 | |
| 5 | 4SP2-28A | 1.5 | 220 | 2.88(16pcs 180Wp) | 1.5 /130 | 2 /118 | 3 /78 | 770 | |
| 6 | 4SP2-33A | 1.5 | 220 | 2.88(16pcs 180Wp) | 1.5 /152 | 2 /139 | 3 /93 | 875 | |
| 7 | 4SP2-40A | 2.2 | 220 | 4.23(18pcs 235Wp) | 1.5 /185 | 2 /169 | 3 /113 | 1022 | |
| 8 | 4SP2-48A | 2.2 | 220 | 4.23(18pcs 235Wp) | 1.5 /223 | 2 /203 | 3 /134 | 1190 | |
| 9 | 4SP3-6A | 0.37 | 48 | 0.72 (4pcs 180Wp) | 1.8 /33 | 3 /28 | 4.2 /16 | 32 /1.25 | 308 |
| 10 | 4SP3-9A | 0.55 | 110 | 1.175(5pcs 235Wp) | 1.8 /50 | 3 /41 | 4.2 /24 | 371 | |
| 11 | 4SP3-12A | 0.75 | 110 | 1.44(8pcs 180Wp) | 1.8 /67 | 3 /55 | 4.2 /33 | 434 | |
| 12 | 4SP3-15A | 1.1 | 220 | 2.115(9pcs 235Wp) | 1.8 /83 | 3 /69 | 4.2 /41 | 497 | |
| 13 | 4SP3-18A | 1.1 | 220 | 2.115(9pcs 235Wp) | 1.8 /100 | 3 /83 | 4.2 /49 | 560 | |
| 14 | 4SP3-22A | 1.5 | 220 | 2.88(16pcs 180Wp) | 1.8 /122 | 3 /101 | 4.2 /60 | 644 | |
| 15 | 4SP3-25A | 1.5 | 220 | 2.88(16pcs 180Wp) | 1.8 /138 | 3 /115 | 4.2 /68 | 707 | |
| 16 | 4SP3-29A | 2.2 | 220 | 4.23(18pcs 235Wp) | 1.8 /158 | 3 /132 | 4.2 /77 | 791 | |
| 17 | 4SP3-33A | 2.2 | 220 | 4.23(18pcs 235Wp) | 1.8 /182 | 3 /153 | 4.2 /89 | 875 | |
| 18 | 4SP5-4A | 0.37 | 48 | 0.72(4pcs 180Wp) | 2.7 /21 | 5 /15 | 6 /10 | 40 /1.5 | 266 |
| 19 | 4SP5-6A | 0.55 | 110 | 1.175(5pcs 235Wp) | 2.7 /32 | 5 /25 | 6 /17 | 308 | |
| 20 | 4SP5-8A | 0.75 | 110 | 1.44(8pcs 180Wp) | 2.7 /43 | 5 /32 | 6 /23 | 350 | |
| 21 | 4SP5-12A | 1.1 | 220 | 2.115(9pcs 235Wp) | 2.7 /63 | 5 /49 | 6 /37 | 434 | |
| 22 | 4SP5-17A | 1.5 | 220 | 2.88(16pcs 180Wp) | 2.7 /90 | 5 /67 | 6 /47 | 539 | |
| 23 | 4SP5-21A | 2.2 | 220 | 4.23(18pcs 235Wp) | 2.7 /110 | 5 /82 | 6 /59 | 623 | |
| 24 | 4SP5-25A | 2.2 | 220 | 4.23(18pcs 235Wp) | 2.7 /132 | 5 /101 | 6 /71 | 707 | |
| 25 | 4SP8-5A | 0.75 | 110 | 1.44(8pcs 180Wp) | 4.2 /26 | 8 /20 | 10.8 /12 | 50 /2 | 361 |
| 26 | 4SP8-7A | 1.1 | 220 | 2.115(9pcs 235Wp) | 4.2 /35 | 8 /27 | 10.8 /17 | 423 | |
| 27 | 4SP8-10A | 1.5 | 220 | 2.88(16pcs 180Wp) | 4.2 /50 | 8 /39 | 10.8 /24 | 516 | |
| 28 | 4SP8-12A | 2.2 | 220 | 4.23(18pcs 235Wp) | 4.2 /61 | 8 /48 | 10.8 /28 | 578 | |
| 29 | 4SP8-15A | 2.2 | 220 | 4.23(18pcs 235Wp) | 4.2 /76 | 8 /60 | 10.8 /36 | 671 | |
| 30 | 4SP14-5A | 1.5 | 220 | 2.88(16pcs 180Wp) | 6 /28 | 14 /20 | 18.9 /6 | 50 /2 | 439 |
| 31 | 4SP14-7A | 2.2 | 220 | 4.23(18pcs 235Wp) | 6 /40 | 14 /27 | 18.9 /8 | 532 | |
