Through hole LED Module Series
Specifications
| Dimension | L91XW14XH7mm | ||||
| LED No | 3 pcs through hole LED | ||||
| Voltage | Input 12VDC | ||||
| View angle | 120 degree | ||||
| Current | 20mA | 20mA | 20mA | 30mA | 30mA |
| Watts | 0.48 | 0.48 | 0.48 | 0.72 | 0.72 |
| Lumen | 20 | 5.25 | 18.5 | 6.5 | 8.5 |
| Cover | Milky ABS | ||||
| Life | 30,000~50,000 hrs. Lumen Maintenance:>92%@1,000hrs |
||||
| Color | White 3500~13000k |
Blue | Green | Yellow | Red |
| Operation Temperature | -40°C- 60°C (-40°F~140°F) | ||||
| Certificate | CE:BTRE0708181359 / RoHS: BTRS0708310889 | ||||
| Warranty | 12 months | ||||
| Weight | 10g/pc.600g/60pcs/bag. | ||||
| IP | IP67 The PCB be covered by resin. | ||||
Features:
·The Lowest Cost
Through hole LED Modules have the best price in all LEDs
·High Brightness
LED Modules consist of 3 through hole LEDs in high intensity and can emit higher brightness at lower cost .No spot. No shadow
·Easy Installation
LED Modules can be easily installed with 3M double-sided sticking tape and connectors.
·Extended Life
LED Modules have a life time of more than 30,000 hours.
·Totally waterproof
With IP67 protection degree, LED Modules can operate normally in cloudy, rainy, desert, and snowy weather conditions and pool. The LEDs are totally covered by resin.
·Friendly environment
Pb free. With CE/RoHS/SGS certificate, LEDs Waterproof LED Modules are up to 60% more energy efficient than neon.
·Safe Application
Low voltage DC12V, safety and stable. Free maintenance
