Big Size Solar Panel (80W-130W)

Name: Big Size Solar Panel (80W-130W)
Brand: Hilight Solar
SKU: 127766239
Availability: InStock

US$ 1.2 - 1.45 MOQ: 2 Pieces

Key Specifications

Place of Origin:

China

Brand Name:

Hilight Solar

Model Number:

HS-P-80WP-130WP

Shandong Hilight-Solar Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin China

Brand Name Hilight Solar

Model Number HS-P-80WP-130WP

Material Polycrystalline Silicon

Size 1200x540x35 ,1482x675x35

Number of Cells 36 PCS ( 4X9)

Max. Power 280 W

Specifications

Solar Module
Power range:1W-280W
Warranty:25 years lifetime
Good delivery time & Competitive Price
Certificate:TUV,UL,CE

Polycrystalline Silicon Solar Module/Solar Panel Technical Parameter

ITEM	Polycrystalline Silicon
Maximum power (Wp)	80W	85W	90W	100W	110W	120W	125W	130W
Maximum power voltage (V)	17.60	17.70	17.90	17.10	17.10	17.50	17.60	17.80
Maximum power current (A)	4.55	4.80	5.02	5.85	6.43	6.86	7.10	7.30
Open circuit voltage (V)	21.80	22.00	22.40	21.20	21.40	21.40	21.60	21.74
Short circuit current (A)	5.00	5.28	5.30	7.39	7.46	7.70	7.90	8.05
Size of solar cells (mm)	125 x 125			156 x 156
Number of cells (Pcs)	36 PCS ( 4X9)			36 PCS ( 4X9)
Size of module (mm)	1200x540x35			1482x675x35
Brand Name of Solar Cells	CEEG or JA SOLAR or SOLARFUN
Maximum system voltage (V)	1000
Temperature coefficients of Isc (%)	+ 0.1/ °C
Temperature coefficients of Voc (%)	-0.38/ °C
Temperature coefficients of Pm (%)	-0.47/ °C
Temperature coefficients of Im (%)	+0.1/ °C
Temperature coefficients of Vm (%)	-0.38/ °C
Temperature Range	-40°C~+80°C
Surface Maximum Load Capacity	60m/s(200kg/sq.m)
Allowable Hail Load	steel ball fall down from 1m height
Weight per piece (kg)	7.8
Junction Box Type	Junction box with TUV certificate
Length of Cables (mm)	900mm
Cell Efficiency (%)	>14%	>15.4%	>15.6%	>13.09%	>14.20%	>13.70%	>14.26%	>14.83%
Module Efficiency (%)	>12%	>14.1%	>14.4%	>12.04%	>12.76%	>12.18%	>12.69%	>13.20%
Output tolerance (%)	±3%
Frame (Material, Corners, etc.)	Aluminum
Standard Test Conditions	AM 1.5,1000W/m2, 25°C
Warranty	5 years product warranty and 20 years 80% of power, 25 years lifetime
