2016 Latest Price 280w Poly Solar Panel

Name: 2016 Latest Price 280w Poly Solar Panel
Brand: Hilight
SKU: 127765099
Availability: InStock

US$ 0.46 - 0.68 MOQ: 10 Watts

Key Specifications

Place of Origin:

Shandong, China

Brand Name:

Hilight

Model Number:

HSPV-P-280w

Shandong Hilight-Solar Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Shandong, China

Brand Name Hilight

Model Number HSPV-P-280w

Specification Normal

Application Home

Output Voltage (V) 35.7v

Load Power (W) 280w

Solar Power (W) 280w

Work Time (h) 210,000

-----Why Choose 280Wp Pv Solar Panel---------

A. Professional Manufacturers Of Mono & Poly Silicon PV Module

B. High Conversion Efficiency Solar Module

C. High transmission rate and low iron tempered glass

D. Anti-aging EVA, high frame resistant TPT to laminate and anodized aluminum alloy frame

E. Long life, Easy installation, high wind and hail impact resistance etc advantage.

F. Be resistant to atmospheric exposure and effects of delamination

G. Strict quality control and power classification of modules

H. Ready to use with junction box, cabling and connectors

I. ISO,CEC, CE , TUV ,IEC/EN61215 IEC/EN61730

J.25years Warranty , 90% of original efficiency in 10years, and 80% in 25years.

-----Specification of 280Wp Pv Solar Panel---------

Module Type	HSPV260Wp-156-72P	HSPV270Wp-156-72P	HSPV280Wp-156-72P	HSPV290Wp-156-72P	HSPV300Wp-156-72P	HSPV310Wp-156-72P
Maximum power at STC (Pmax)	260w	270w	280w	290w	300w	310w
Maximum power voltage (Vmp)	35.3	35.5	35.7	35.9	36.1	36.3
Maximum power current (Imp)	7.37	7.61	7.84	8.08	8.31	8.54
Open circuit voltage (Voc)	43.0	43.2	44.3	43.7	44.0	44.3
Short circuit current (Isc)	8.06	8.33	8.62	8.73	8.97	9.20
Nominal Operating Cell Temperature	45 ± 2°C
Temperature coefficients of Isc	+0.049% /°C
Temperature coefficients of Voc	-0.340% /°C
Temperature coefficients of Pmax	-0.430% /°C
Standard Test Conditions (STC)	Irradiance 1000W/m2, Module temperature 25°C, Air Mass (AM)=1.5
Power Production Tolerance	± 3%
