Help Center260w Poly/multi Crystalline Solar Panel Pv Module With Tuv Ce Cec Pv Cycle Soncap Approval Standard
Related Products
-
Photovoltaic Panel Price 280wUS$ 0.46 - 0.65MOQ: 50 Watts -
High Efficiency Photovoltaic Solar Panel 235w Use In RoofUS$ 0.48 - 0.65MOQ: 50 Watts
-
2016 Hot Sale Poly Solar pv Module Solar Panel 235wUS$ 0.47 - 0.65MOQ: 50 Watts
-
High Efficiency Pv 235w Solar Cell PanelUS$ 0.46 - 0.65MOQ: 50 Watts
-
High Quality HSPV 235w Tuv Pv Solar Panels With Factory Direct Low PriceUS$ 0.46 - 0.64MOQ: 50 Watts
-----Why Choose HSPV 260w Solar Panel Pv Module --------
A. Professional Manufacturers Of Mono & Poly Silicon PV Module
B. High Conversion Efficiency Solar Module
C. High transmission rate and low iron tempered glass
D. Anti-aging EVA, high frame resistant TPT to laminate and anodized aluminum alloy frame
E. Long life, Easy installation, high wind and hail impact resistance etc advantage.
F. Be resistant to atmospheric exposure and effects of delamination
G. Strict quality control and power classification of modules
H. Ready to use with junction box, cabling and connectors
I. ISO,CEC, CE , TUV ,IEC/EN61215 IEC/EN61730
J.25years Warranty , 90% of original efficiency in 10years, and 80% in 25years.
----- 260Wp Solar Panel Pv Module ---------
| Module Type | HSPV-255Wp-156-66P | HSPV-260Wp-156-66P | HSPV-265Wp-156-66P |
| Maximum power at STC (Pmax) | 255w | 260w | 265w |
| Maximum power voltage (Vmp) | 32.9 | 33.0 | 33.0 |
| Maximum power current (Imp) | 7.75 | 7.88 | 8.03 |
| Open circuit voltage (Voc) | 39.7 | 39.8 | 40.0 |
| Short circuit current (Isc) | 8.56 | 8.60 | 8.72 |
| Nominal Operating Cell Temperature | 45 ± 2°C | ||
| Temperature coefficients of Isc | +0.049% /°C | ||
| Temperature coefficients of Voc | -0.340% /°C | ||
| Temperature coefficients of Pmax | -0.430% /°C | ||
| Standard Test Conditions (STC) | Irradiance 1000W/m2, Module temperature 25°C, Air Mass (AM)=1.5 | ||
| Power Production Tolerance | ± 3% | ||
----- 260Wp Solar Panel Pv Module ------
----- 260Wp Solar Panel Pv Module ---------
----- 260Wp Solar Panel Pv Module ---------
----- Certificates of 260Wp Solar Panel Pv Module ---------
-----Kindly contact me if there is any question---------
