Solar Panel Manufacturing, Small Photovoltaic Panels, Chinese Photovoltaic Panels with IEC CE ISO certificates
Solar Panel Manufacturing, Small Photovoltaic Panels, Chinese Photovoltaic Panels
| Module Type | HSPV10Wp-156P | HSPV20Wp-156P | HSPV30Wp-156P | HSPV40Wp-156P |
| Maximum power at STC (Pmax) | 10w | 20w | 30w | 40w |
| Maximum power voltage (Vmp) | 17.5 | 17.6 | 17.6 | 17.6 |
| Maximum power current (Imp) | 0.57 | 1.14 | 1.72 | 2.28 |
| Open circuit voltage (Voc) | 21.8 | 21.8 | 21.8 | 21.8 |
| Short circuit current (Isc) | 0.61 | 1.21 | 1.83 | 2.42 |
| Dimensions of module (mm) | 420x260x17mm | 540x360x17mm | 350x670x25mm | 420x670x25mm |
| Module Area (m*m) | 0.11 | 0.19 | 0.23 | 0.28 |
| Nominal Operating Cell Temperature | 45 ± 2℃ | |||
| Temperature coefficients of Isc | +0.049% /℃ | |||
| Temperature coefficients of Voc | -0.340% /℃ | |||
| Temperature coefficients of Pmax | -0.430% /℃ | |||
| Standard Test Conditions (STC) | Irradiance 1000W/m2, Module temperature 25℃, Air Mass (AM)=1.5 | |||
| Power Production Tolerance | 0~+ 3% | |||
| Solar Cell | Poly solar cells |
| Front Cover | 3.2 mm thick, tempered glass |
| Back Cover | TPT (Tedlar-PET-Tedlar) |
| Encapsulant | EVA (ethylene vinyl acetate) |
| Frame | Double-layer anodized aluminium alloy |
| Junction Box | IP65 rated |
| Maximum System Voltage | DC1000V (IEC) |
| Maximum Series Fuse | 15 A |
| Operating Temperature | -40℃~+85℃ |
| Storage Temperature | -40℃~+85℃ |
| Max. Wind Load / Max. Snow Load | 2400Pa / 5400Pa |
| Application Class | Class A |
| Packing configuration | Carton. Customers packing requirement is acceptable. |
Customers packing requirement is acceptable.
| By Sea | Delivery from Qingdao, Shanghai or Ningbo seaport. |
| By Air | Departure from Qingdao, Beijing or Shanghai Airport |
| By Express | Post by DHL,UPS,TNT, FedEx. |
| Payment Terms | T/T | EXW | 30% T/T in advance, paid the balance before shipment | |||
| FOB | ||||||
| CFR(C&F) | 30% T/T in advance, paid the balance against copy of B/L | |||||
| CIF | ||||||
| L/C | L/C amount above 30,000 usd, we can accept L/C at sight | |||||
| Trade Assurance |
100% product quality protection 100% on-time shipment protection 100% payment protection for your covered amount |
|||||
| Western Union | Amount lower than 5000usd | |||||
| Paypal | ||||||
| Delivery time | 10~15days after receiving payment for one container | |||||
| 10 years for product defects in materials & workmanship | |
| 25 years transferrable power output warranty | 10 years at 90% of the minimal rated power output |
| 25 years at 80% of the minimal rated power output | |
1.Does HILIGHT Solar offer PV solutions for commercial and industrial utilities?
Yes, HILIGHT Solar offers the most cost effective PV solutions for commercial and industrial utilities seeking to meet renewable portfolio standards requirements. Please contact our sales and product management team for more information.
2.Does HILIGHT Solar sell to distributors or wholesalers?
Yes, HILIGHT Solar currently is selling its products through distributors, resellers, or wholesalers. And agent are wanted now. For more information, please contact our sales and management team.
3.Does HILIGHT Solar offer a warranty for its solar modules?
HILIGHT Solar provides a power output warranty for 25 years subject to terms and conditions and a materials and workmanship warranty for five to ten years covering defects in materials and workmanship under normal use and service conditions.
4.What are the possible problems with solar panels and how can I prevent them?
Solar panel failure is most often caused by water damage to the panel, sealant, or connections. To prevent damage or failure, mount the panel carefully. Be sure not to fix it horizontally, which encourages water collection in the frame. Also, allow for a sufficient air gap beneath the panel. Keeping your panel dry and clean will ensure efficient, maximum output.
5.Are solar electric systems safe?
Yes. Solar cells are mostly silicon, the primary component of sand. There is no exhaust and no toxic materials to leak out of the system. The electricity coming through the inverter is just like the electricity coming from household wall sockets; you should use the same care you would with utility power. All components are approved for utility interconnection and are installed according to standard construction practices.
