DJI NAZA PMU V2

DJI NAZA PMU V2 thumbnail-1
DJI NAZA PMU V2 thumbnail-2
DJI NAZA PMU V2 thumbnail-3
DJI NAZA PMU V2 photo-1
DJI NAZA PMU V2 photo-2
DJI NAZA PMU V2 photo-3
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Type:
Helicopter
Power:
Battery
Radio Control Style:
RC Hobby
Contact Supplier Request Quote Chat Now
Magicsky Middle East Fze
Payment & Shipping
Payment Methods:
Port of Shipment:
Jebel Ali Dubai UAE
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Type Helicopter
Power Battery
Radio Control Style RC Hobby
Place of Origin United Arab Emirates
Brand Name DJI
Model Number DJI NAZA PMU V2

Specifications

The Naza PMU V2 has enhanced BEC functionality and provides extendable CAN BUS ports, which can support iOSD, Zenmuse H3-2D.

The DJI Naza M PMU V2 for Phantom Fly with H3-2D is a compact power management unit (PMU) that features enhanced BEC functionality and extendable CAN BUS ports. It can be used as an independent PMU for the DJI Zenmuse H3-2D brushless gimbal when used with your DJI Phantom quadcopter. However, if you already have the DJI Phantom Upgrade Kit for Zenmuse H3-2D installed in your Phantom quadcopter, then this Naza M PMU V2 is not required to use the gimbal with your Phantom quadcopter. The PMU's extendable CAN BUS ports will support the Zenmuse H3-2D gimbal pitch control function as well. Plus, it will also work with the optional DJI iOSD for collecting real-time flight data and the optional Bluetooth LED module. That means you'll be able adjust parameters at any time via a mobile app on your smartphone or tablet.

Compact power management unit (PMU) with enhanced BEC functionality and extendable CAN BUS ports

Works as independent PMU for the Zenmuse H3-2D brushless gimbal

Enables pitch control when used with the Zenmuse H3-2D brushless gimbal on the DJI Phantom

Works with the optional DJI iOSD for collecting real-time flight data, which can then be transmitted to ground end using an optional video link accessory

Works with the optional Bluetooth LED module for adjusting parameters at any time via a mobile app on your smartphone or tablet



Specifications:

Interfaces

Extended CAN port x 1 (for Zenmuse GCU connection)

GPS/Compass module connector port x 1

V-SEN X3 port connector plug x 1 (for main controller)

EXP port connector plug x 1 (for main controller)

Continuous Power Output 3 A at 5 V

Maximum Current 7.5 A

Power Source Lithium-polymer battery (2S - 6S)

Battery Voltage 7.4 - 26.0 V
