Small Construction Machinery 17 years Screw Cement Grout Pump/mortar pump machine :
Technical specification:
Type |
GLP-3II |
Production Capacity |
3m³/h |
Working Pressure |
3MPa |
Rate of Applicable Materials |
Water:Mortar:Sand=(0.7-1):1:3 |
Horizontal Delivery Distance |
20m |
Inner Size of Hose |
Ø 32mm |
Maximum Aggregate Size |
Ø ≤4mm |
Hopper volume |
50L |
Air Compressor |
3m³/h |
Motor Power |
7.5KW |
Voltage |
380v or as Your Request |
Dimension |
2000x500x1150mm |
Net Weight |
360KG |
The features of Spraying machine:
1, reasonable design, integration of pump and compressor, easy to move.
2, feeding smoothly , no pulse phenomenon;
3, wide applicability, can spray powder, mortar, can also spray mortar;
4, coating uniformity, strong adhesion;
5, complete functions, can spray can coating;
6, can change the connection direction of the spray gun and nozzle, easy to operate.
Ecnomic Benefits:
1. Few Fall Mortar,Water saving, material saving,can reduce cost by more than 20%.
2. High efficiency,a set Mortar Plastering Machine can paint 150 square meters per hour with ease,if it works 8 hours one day,then it can Paint more or less 1000 square meters ,which equals to the workload of 20 skilled workers per day.
3. Engineering quality assured,our company launched high pressure spraying equipment flow (up to 3 mpa) to overcome the shortcomingslow degree of the compactness of cement mortar;low adhesive property between the wall and mortar.the degree of compatness is far exceed the standards prescribed by the state, to avoid the trouble and loss caused due to the quality of the construction period wages, etc.
4. Multiusage,this Mortar Spraying Machine can be used to spray mortar,refractory material,fire protection materials,etc. not restricted by regional and environmental conditions and spraying surface shape.
Standard production, strict and regulate assembly line work, strict quality control and inspection.
Our company go through the international BV certification authority, and we have the ability to provide you the products with reliable quality, competitive price and timely service.
Professional sales and after sale service team, timely and efficiently to solve your problem.
Sincerely welcome you to visit, consult and negotiate business.
