Specifications
silver mirror,gold mirror and so onWARRANTY 10 YEARS
ANY COLORS
Additional Info.
Product Description
ONEBOND Mirror is available in all colors, (The most popular ones are Gold/Siliver/Black Mirror) to meet the high-class decoration requirement. The durable and ultra-reflective mirror finish weights just half as much as a glass mirror of the same thickness. Another outstanding characteristic compared to mirrors out of glass is that ONEBOND Mirror would not Burst- an essential criterion for public safety areas. Last but not least, easy processing and good formability are another unparalleled feature by the well-known performance of ONEBOND aluminum composite panel properties. ONEBOND Mirror with its elegant, exclusive appearance, easy for transport, fixing and handling, meets actual market trends in retail design, shop design, hotel, leisure industries and exhibition stand building. Standard Products: For Exterior: 1220X2440X4MM, al: 0.3mm, 0.4mm, 0.50MM, PVDF For Interior: 1220X2440X3MM, al: 0.10mm, 0.12MM, 0.18MM. 0.21MM PE Products Available: Thickness: 2mm, 3mm, 4mm, 5mm, 6mm, 7mm, 8mm Length: Can be customized Width: 800mm~1570mm Aluminum thickness: 0.12mm, 0.18MM, 0.21mm, 0.30mm, 0.40mm, 0.50mm Coating: Polyester coating, Fluorocarbon coating. Scope of Application: Internal and external decoration for all kinds of buildings, airports, ceilings, tunnels, billboards, doors, furniture, car bodies, ships, etc. Cutting: Cut with a saw, cutter, or trimmer. Cleaning and Maintenance: Clean with water or neutral cleaner, using a soft cloth. Do not use force. Do not use a knife or other sharp object.
Color Chart
| Thickness | Unit | 6 mm | 10 mm | 15 mm | 20 mm | 25 mm | |||
| Cover sheet thickness, front | [mm] | 1.0 | |||||||
| Cover sheet thickness, rear | [mm] | 0.5 | 0.5 | 1.0 | 1.0 | 1.0 | |||
| Weight | [kg/m²] | 4.7 | 5.0 | 6.7 | 7.0 | 7.3 | |||
| Technical properties | |||||||||
| Section modulus | W | [cm³/m] | 2.6 | 4.6 | 14 | 19 | 24 | ||
| Rigidity | E@J | [kNcm²/m] | 7.100 | 21.900 | 75.500 | 138.900 | 221.600 | ||
| Alloy / Temper of Aluminium Layers | Peraluman alloy (AIMg), H42 acc. EN 573-3 | ||||||||
| Modulus of Elasticity | E | [N/mm²] | 70.000 | ||||||
| Tensile Strength of Aluminium | R m | [N/mm²] |
|
||||||
| 0.2 % Proof Stress | R p0,2 | [N/mm²] |
|
||||||
| Elongation | A 50 | [%] |
|
||||||
| Linear Thermal Expansion | α | 2.4 mm/m at 100ºC temperature difference | |||||||
| Core | |||||||||
| Aluminium foils from AIMn alloys (EN AW-3003) Bare comprehensive strength | [N/mm²] | > 2.5 | |||||||
| Weight | [kg/m³] | > 50 | |||||||
| Surface | |||||||||
| Lacquering | Coil Coating Fluorocarbon based (e.g. PVDF) | ||||||||
| Gloss (initial value) | [%] | 25-40 | |||||||
| Pencil Hardness | HB-F | ||||||||
| Acoustical Properties | |||||||||
| Sound Absorption Factor | α s | 0.05 | |||||||
| Airborne sound insulation index (acc. to ISO 717-1, ISO 140-3) | R w | [dB] | 21 | 21 | 22 | 23 | 25 | ||
| Thermal Properties | |||||||||
| Termal conductivity (regarding total thickness, incl. cover sheets) | λ | [W/mK] | 0.95 | 1.35 | 1.78 | 2.25 | 2.70 | ||
| Thermal resistance | R | [m²K/W] | 0.0063 | 0.0074 | 0.0084 | 0.0089 | 0.0093 | ||
| Temperature Resistance | [ºC] | -40 to +80 | |||||||
