Specifications
fireproof grade A2USA PPG PVDF COATING
WARRANTY 20YEARS
ANY COLORS
Product Description
FIREPROOF ACP FOR MORE FIRE SAFETY Fireproof Aluminium Composite Panel is a fire-safe material with a flame-retardant mineral core or non-combustible core to prevent the proliferation of flames and restrict the development of smoke detrimental to evacuation activities. This is developed exclusively for the higher requirements of the fire regulation in architecture. It meets the BS, ASTM standard testing by SGS Lab, and reach GB 8624-2006 B-s1, d0, t0 grade and Non-combustible Class A. Inherit the advantage of Aluminum composite panels characteristics, Fireproof Aluminium Composite Panel is an ideal fire-safe material for interior/exterior architecture. Constitution structure:
Standard Products: For Exterior: 1220X2440X4MM, al: 0.3mm, 0.4mm, 0.50MM, PVDF For Interior: 1220X2440X3MM, al: 0.10mm, 0.12MM, 0.18MM. 0.21MM PE Products Available: Thickness: 2mm, 3mm, 4mm, 5mm, 6mm, 7mm, 8mm Length: Can be customized Width: 800mm~1570mm Aluminum thickness: 0.12mm, 0.18MM, 0.21mm, 0.30mm, 0.40mm, 0.50mm Coating: Polyester coating, Fluorocarbon coating. Scope of Application: Internal and external decoration for all kinds of buildings, airports, ceilings, tunnels, billboards, doors, furniture, car bodies, ships, etc. Cutting: Cut with a saw, cutter, or trimmer. Cleaning and Maintenance: Clean with water or neutral cleaner, using a soft cloth. Do not use force. Do not use a knife or other sharp object. FR Aluminum composite panel. Completely meets the fire safefy requirement according to BS 476 Part 6, ASTM E-84, and China GB8624 standards
FR Conforms to:
CountryStandardGrade ChinaGB8624B-s1, d0, t0 Europe EN13501B-s1, d0 U. S. AASTM E84A U. KBS 4760, 1
Tested according to BS, ASTM Standard:
TESTING ITEMSTEST CONDITIONRESULTCONCLUSIONSTANDARD Fire safety testBS 476 Part 6: 1989Total fire propagation Index: 0.05Class 0BS 476: Part 6: 1989 Fire safety testRelative Humidity of 50 10F Temperature of 23 2 CFlame spread at 1.5min: 60mmClass 1BS 476: Part 7: 1997 Final flame spread: 60mm Fire safety testRelative Humidity of 50 5F Temperature of 73 5 CFlame spread index: 10Class AASTM E-84-04 Smoke develcped value: 15 BS: British Standard; ASTM: American Society for Testing and Materials
Conclusion: Since the sample receives a Flame Spread of 10 and a smoke Developed Value of 15, it will fall into the Class A Interior Wall & Ceiling Finish Category. And completely meets the China GB/T 8624, Grade B-s1, d0, t0 standards require.
