Widely used to construction good quality Cement Mortar Spray Pump,Cement Grouting Pump Machine :
Technical Parameter:
Item(GS20E) |
Unite |
Paramete |
|||
Output |
L/H |
1800 |
|||
Motor Power |
kW |
5.5 |
|||
Max Aggregate size |
mm |
≤4 |
|||
Working Pressure |
MPa |
2.5-5.0 |
|||
Grouting Pressure |
MPa |
2.5-5.0 |
|||
Conveying Distance |
Vertical |
m |
0(concrete) |
40(cement and sand) |
80(cement) |
|
Horizontal |
m |
160(Cement) |
||
Hopper Capacity |
L |
110 |
|||
Filling Height |
mm |
670 |
|||
Dimension(L*W*H) |
mm |
1500*660*910 |
|||
Weight |
kg |
280 |
|||
Structure and feature:
This pump is new structure, avoide difficult when grouting thick concrete. Easy to operate, high efficiency.
This machine is mainly compose by motor reducer, t Transport slurry body, supercharge screw, supercharge stator, manometry, hopper( The feed tray ), electric control system, etc., when used in the spray guard, also includes the injector, which is characterized as follows:
1. the structure is compact and simple, high reliability, the use of imported electrical appliances.
2. easy to operate and maintain.
3. light weight, wheel design, easy to move.
4. wide grouting liquid water-cement ratio range, especially suitable for the high concentration of the design requirements of a thick paste.
5. Capable of filling slurry ash aggregate, particle size range
6. continuous filling, to avoid excessively large instantaneous pulsating pressure of the piston pump.
7. passively Boost. When the slurry is filled, the pressure is gradually increased, easy to control and maintain the grouting pressure.
8, When the grouting pressure reaches the design pressure, reversal relief.
9, When use with the air compressor and injectors, can do interior and exterior underlying overlay layer spray guard.
Application
The machine can be widely used in road, rail tunnels, city subway, hydropower underground cavern bolt grouting, consolidation grouting, backfilling and grouting anchor perfusion pulp works, can be used for the dam, slope, soil soft rock reinforcement layer curtain grouting pressure grouting engineering, can also be used for urban construction works within the external walls of the underlying and Overlay spray lining construction.
Our company go through the international BV certification authority, and we have the ability to provide you the products with reliable quality, competitive price and timely service.
Professional sales and after sale service team, timely and efficiently to solve your problem.
1.Package:
Free-fumigation Safe Export Wood Case.
2.MOQ
1set can be acceptable for trail order.
Over 3sets can have wholesale price.
Welcome to join us as our sales agent in your market.
3.OEM and ODM
changing on design or color: acceptable(welcome)
develop on artwork and sketch: acceptable
4.QC Third party inspection: acceptable
1 year guarantee for quality problems
5.Delivery time:
1 week for our own design.(motor:380v 50hz 3phases)
15-25days for cusmoized model.
6.Payment :
TT, 30% deposit ,70% before shippment. L/C at sight (high bank charge, not suggest , but acceptable ) 100%TT in advance (specially for air shipment or small amount)
7.Available shipment:
FOB Qingdao
FOB Shanghai
Sincerely welcome you to visit, consult and negotiate business.
