BW-160/10 Mud Pump 1400*850*950 horizontal, triplex. single acting reciprocation piston pump
BW-160 mud pump is a horizontal, triplex, single acting reciprocation piston pump. It's function is to supply the drilling hole with flushing liquor in order to cool bit. It is used matching drill rigs. It is applied to geological and engineering prospecting such as the railway, the water conservancy, the met-allurgy, the build and the geology etc industry whose hole deep is within 1000m.
Also it can be used to deliver water to high mountains or in the execution domain of middle and low pressure grouting and non excavating matching. This pump has advantages such as small cubage, light mass, long life, simple operation and reliable per-formance, etc
Model number |
BW-160 |
Type |
horizontal, triplex. single acting reciprocation piston pump |
Stroke(mm) |
70 |
Dia. of piston(mm) |
70 |
Pump speed(min) |
200 132 83 55 |
Output volume(1/min) |
160 107 67 44 |
Pressure(Mpa) |
2.5 4 6.5 10 |
Volumetric efficiency(%) |
95 |
Overall efficiency(%) |
75 |
Input hose diameter(mm) |
51 |
Output hose diameter(mm) |
32 |
Power of dynamic force(Kw) |
11 13.24 |
Rotate speed of dynamics force(r/min) |
1460 2200 |
Overall size(length*width*height) |
1400*860*950 |
Mass(kg) |
380 |
