Home > Manufacturing & Processing Machinery > Laser Equipment > Laser Cutting Machine > QC11Y-16x3200 Chinese Good Quality Manual Hydraulic Stainless Plate Shearing Machine
QC11Y-16x3200 Chinese Good Quality Manual Hydraulic Stainless Plate Shearing Machine
US$ 3,500 - 35,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Jiangsu, China
Brand Name:
SC
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
QC11K-16X1000 CNC Sheet Metal Hydraulic Guillotine Shearing Machine FactoryUS$ 4,000 - 28,000MOQ: 1 Set -
QC11Y-16x1000 Cut to Length Line Used Hydraulic Plate Shearing Machine FactoryUS$ 5,000 - 30,000MOQ: 1 Set
-
QC11Y-12X4000 Wuxi High Quality Reasonable Price Hydraulic Shearing MachineUS$ 3,000 - 35,000MOQ: 1 Set
-
QC12Y-8x3200 Customize Design Hydraulic Swing Beam ShearUS$ 1,000 - 15,000MOQ: 1 Set
-
QC11YK-25X3200 Hydraulic Metal Shearing MachineUS$ 10,000 - 100,000MOQ: 1 Case
Condition
New
Place of Origin
Jiangsu, China
Brand Name
SC
Model Number
QC11Y-16x3200
Voltage
220V,380V
Rated Power
customize
Certification
CE, SGS, ISO
Warranty
12 Months
After-sales Service Provided
Engineers available to service machinery overseas
Specifications
1.Manual plate shearing machine2.ISO, SGS & CE certification
3.Professional factory
4.Customize design
5. Easy operation
Details of QC11Y-16x3200 manual hydraulic plate shearing machine
Welded steel plate construction, eliminate internal stress by heat treatment, with high strength and good rigidity.
Advanced integrated hydraulic system with an excellent reliability.
The rolling guide with 3-point support and improves the shearing quality.
Rapidly, accurately and conveniently adjusting the blade clearance with the handwheel.
The rectangular blades featuring long lifetime with 4 cutting edges
The adjustable rake angle can minmize plate deformation.
As the cutting beam has been designed in inner-inclined structure, it is easy for plates to fall down and the accuracy of products can also be guaranteed
A light alignment device makes shearing much easier and more efficient
Technical data of durable steel guillotine shearing machine
| Modeks | Mild Steel (450MPa) | Cutting Length (mm) | Back Gauge Range(mm) | Depth Of Thoat(mm) | Rake Angle Adjustment | Strokes Per Minute | Main Motor(KW) | L×W×H (mm) | Weight(T) |
| 6×2500 | 6 | 2500 | 750 | 80 | 0.5°1.5° | 14 | 7.5 | 3100×1725×1960 | 5.3 |
| 6×3200 | 6 | 3200 | 750 | 80 | 0.5°1.5° | 12 | 7.5 | 3650×1750×1980 | 6.5 |
| 6×4000 | 6 | 4000 | 750 | 80 | 0.5°1.5° | 10 | 7.5 | 4650×1780×2075 | 7.5 |
| 6×5000 | 6 | 5000 | 750 | 80 | 0.5°1.5° | 8 | 7.5 | 5650×1830×2250 | 10.5 |
| 6×6000 | 6 | 6000 | 750 | 80 | 0.5°1.5° | 8 | 7.5 | 6650×1890×2380 | 15.2 |
| 8×2500 | 8 | 2500 | 750 | 80 | 0.5°1.5° | 14 | 7.5 | 3100×1725×1960 | 6 |
| 8×3200 | 8 | 3200 | 750 | 80 | 0.5°1.5° | 12 | 7.5 | 3850×1750×1980 | 6.8 |
| 8×4000 | 8 | 4000 | 750 | 80 | 0.5°1.5° | 10 | 7.5 | 4650×1850×2075 | 8.5 |
| 8×5000 | 8 | 5000 | 750 | 80 | 0.5°2° | 7 | 15 | 5805×2000×2500 | 12.5 |
| 8×6000 | 8 | 6000 | 750 | 100 | 0.5°2° | 7 | 15 | 6805×2115×2715 | 19.8 |
| 10×2500 | 10 | 2500 | 750 | 120 | 0.5°2.5° | 10 | 15 | 3195×1800×2210 | 8.2 |
| 10×3200 | 10 | 3200 | 750 | 120 | 0.5°2.5° | 8 | 15 | 3895×1800×2240 | 9.15 |
| 10×4000 | 10 | 4000 | 750 | 120 | 0.5°2.5° | 6 | 15 | 4695×1930×2275 | 11 |
| 10×5000 | 10 | 5000 | 750 | 120 | 0.5°2.5° | 5 | 15 | 5905×2115×2715 | 16 |
| 10×6000 | 10 | 6000 | 750 | 120 | 0.5°2.5° | 5 | 15 | 6905×2215×2800 | 22 |
| 12×2500 | 12 | 2500 | 750 | 120 | 0.5°2.5° | 10 | 15 | 3195×1800×2210 | 8.7 |
| 12×3200 | 12 | 3200 | 750 | 120 | 0.5°2.5° | 8 | 15 | 3895×1800×2240 | 9.8 |
| 12×4000 | 12 | 4000 | 750 | 120 | 0.5°2.5° | 6 | 15 | 4710×1950×2485 | 13.4 |
| 12×5000 | 12 | 5000 | 750 | 120 | 0.5°2.5° | 5 | 18.5 | 5905×2115×2800 | 20 |
| 12×6000 | 12 | 6000 | 750 | 120 | 0.5°2.5° | 4 | 18.5 | 7000×2300×3100 | 29 |
| 16×2500 | 16 | 2500 | 750 | 120 | 0.5°2.5° | 8 | 15 | 3215×1880×2340 | 9 |
| 16×3200 | 16 | 3200 | 750 | 120 | 0.5°2.5° | 7 | 15 | 3915×1880×2445 | 11 |
| 16×4000 | 16 | 4000 | 750 | 120 | 0.5°1.5° | 6 | 15 | 4715×1950×2590 | 15 |
| 16×5000 | 16 | 5000 | 750 | 120 | 0.5°3° | 5 | 22 | 6000×2300×3000 | 23 |
| 16×6000 | 16 | 6000 | 750 | 120 | 0.5°3° | 4 | 37 | 7000×2300×3100 | 36 |
| 20×2500 | 20 | 2500 | 750 | 120 | 0.5°3° | 6 | 22 | 3215×1890×2465 | 11 |
| 20×3200 | 20 | 3200 | 750 | 120 | 0.5°3° | 5 | 30 | 4120×1890×2780 | 18 |
| 20×4000 | 20 | 4000 | 750 | 120 | 0.5°3° | 4 | 30 | 4925×2150×2900 | 21 |
| 20×5000 | 20 | 5000 | 750 | 120 | 0.5°3° | 4 | 37 | 6000×2300×3050 | 29 |
| 25×2500 | 25 | 2500 | 750 | 120 | 0.5°3.5° | 5 | 30 | 3435×2000×2710 | 15.3 |
| 25×3200 | 25 | 3200 | 750 | 120 | 0.5°3.5° | 5 | 30 | 4120×2200×3000 | 21 |
| 25×4000 | 25 | 4000 | 750 | 120 | 0.5°3.5° | 3 | 30 | 4950×2200×3150 | 26 |
| 30×2500 | 30 | 2500 | 750 | 120 | 1°3.5° | 4 | 30 | 3435×2020×2770 | 17 |
| 30×3200 | 30 | 3200 | 750 | 120 | 1°3.5° | 3 | 37 | 4200×2300×3200 | 23 |
