QC11Y-20x3200 High quality shear cutting machine , shear machines factory

Specifications

1.shear cutting machine
2.ISO, SGS & CE certification
3.Professional factory
4.High precision
5.Easy operate



QC11Y-20x3200 High quality shear cutting machine , shear machines factory



Welded steel plate construction, eliminate internal stress by heat treatment, with high strength and good rigidity.



Advanced integrated hydraulic system with an excellent reliability.



The rolling guide with 3-point support and improves the shearing quality.



Rapidly, accurately and conveniently adjusting the blade clearance with the handwheel.



The rectangular blades featuring long lifetime with 4 cutting edges



The adjustable rake angle can minmize plate deformation.



As the cutting beam has been designed in inner-inclined structure, it is easy for plates to fall down and the accuracy of products can also be guaranteed.



A light alignment device makes shearing much easier and more efficient







Technical data

Modeks	Mild Steel (450MPa)	Cutting Length (mm)	Back Gauge Range(mm)	Depth Of Thoat(mm)	Rake Angle Adjustment	Strokes Per Minute	Main Motor(KW)	L×W×H (mm)	Weight(T)
6×2500	6	2500	750	80	0.5°1.5°	14	7.5	3100×1725×1960	5.3
6×3200	6	3200	750	80	0.5°1.5°	12	7.5	3650×1750×1980	6.5
6×4000	6	4000	750	80	0.5°1.5°	10	7.5	4650×1780×2075	7.5
6×5000	6	5000	750	80	0.5°1.5°	8	7.5	5650×1830×2250	10.5
6×6000	6	6000	750	80	0.5°1.5°	8	7.5	6650×1890×2380	15.2
8×2500	8	2500	750	80	0.5°1.5°	14	7.5	3100×1725×1960	6
8×3200	8	3200	750	80	0.5°1.5°	12	7.5	3850×1750×1980	6.8
8×4000	8	4000	750	80	0.5°1.5°	10	7.5	4650×1850×2075	8.5
8×5000	8	5000	750	80	0.5°2°	7	15	5805×2000×2500	12.5
8×6000	8	6000	750	100	0.5°2°	7	15	6805×2115×2715	19.8
10×2500	10	2500	750	120	0.5°2.5°	10	15	3195×1800×2210	8.2
10×3200	10	3200	750	120	0.5°2.5°	8	15	3895×1800×2240	9.15
10×4000	10	4000	750	120	0.5°2.5°	6	15	4695×1930×2275	11
10×5000	10	5000	750	120	0.5°2.5°	5	15	5905×2115×2715	16
10×6000	10	6000	750	120	0.5°2.5°	5	15	6905×2215×2800	22
12×2500	12	2500	750	120	0.5°2.5°	10	15	3195×1800×2210	8.7
12×3200	12	3200	750	120	0.5°2.5°	8	15	3895×1800×2240	9.8
12×4000	12	4000	750	120	0.5°2.5°	6	15	4710×1950×2485	13.4
12×5000	12	5000	750	120	0.5°2.5°	5	18.5	5905×2115×2800	20
12×6000	12	6000	750	120	0.5°2.5°	4	18.5	7000×2300×3100	29
16×2500	16	2500	750	120	0.5°2.5°	8	15	3215×1880×2340	9
16×3200	16	3200	750	120	0.5°2.5°	7	15	3915×1880×2445	11
16×4000	16	4000	750	120	0.5°1.5°	6	15	4715×1950×2590	15
16×5000	16	5000	750	120	0.5°3°	5	22	6000×2300×3000	23
16×6000	16	6000	750	120	0.5°3°	4	37	7000×2300×3100	36
20×2500	20	2500	750	120	0.5°3°	6	22	3215×1890×2465	11
20×3200	20	3200	750	120	0.5°3°	5	30	4120×1890×2780	18
20×4000	20	4000	750	120	0.5°3°	4	30	4925×2150×2900	21
20×5000	20	5000	750	120	0.5°3°	4	37	6000×2300×3050	29
25×2500	25	2500	750	120	0.5°3.5°	5	30	3435×2000×2710	15.3
25×3200	25	3200	750	120	0.5°3.5°	5	30	4120×2200×3000	21
25×4000	25	4000	750	120	0.5°3.5°	3	30	4950×2200×3150	26
30×2500	30	2500	750	120	1°3.5°	4	30	3435×2020×2770	17
30×3200	30	3200	750	120	1°3.5°	3	37	4200×2300×3200	23
